Brake Disc
Brake Disc 1 Brake Disc 2 Brake Disc 3
Braking System

Brake Disc

Part No. BG3900 · SKU BG3900-DELPHI
Front Axle
₱17,400.00
In stock — available to order
Genuine & OEM parts Nationwide delivery Easy returns

Specifications

Brake Disc Thickness (mm)22
Brake Disc Type Vented
Centering Diameter (mm)79
Height (mm)73
Minimum thickness (mm)20.4
Number of Holes 5
Outer Diameter (mm)292
Brake Disc Thickness [mm] 22, Brake Disc Type Vented, Centering Diameter [mm] 79, Height [mm] 73, Minimum thickness [mm] 20,4, Number of Holes 5, Outer Diameter [mm] 292
Fits: BMW

Supplier Cross-References

BMW / MINI34116854997 DELPHIBG3900 ZIMMERMANN150342400 FERODODDF1229 ATE24012202381 HELLA PAGID355111231

Interchangeable Part Numbers

A.B.S.17601 ALFA DR6535 ALFADR6535 APECDSK2303 ATE-CN24-0122-0238-1-02 ATE-CN422238 BENDIX562317B Brake ENGINEERINGDI956484 BREMBO09.9752.10 BREMBO09.9752.11 BREMBO09.9752.14 BREMBO09.9752.75 BREMBOFD.166.000 COMLINEADC1717V FEBI BILSTEIN23536 fri.tech.DF1072 FTEBS5435 GIRLING6044491 HELLA 8DD 355111-241 HELLA8DD355111241 HP (ZEBRA)58281 JURATEKBMW107 KAGER37-1107 MAGNETI MARELLI351067920500 MEYLE 315 5213063/PD MEYLE3155213063PD MEYLE 315 5213063 MEYLE3155213063 MGAD1581 MINTEXMDC1646 MOTAQUIPVBD1161 NationalNBD1303 NK201555 OPTIMALBS-7562 PAGID54328 PILENGAV109 QUINTON HAZELLBDC5435 QUINTON HAZELLBDC5435HC QUINTON HAZELLBDC5435P ROADHOUSE6652.10 sbs1815201555 TRWDF4449 TRWDF4449BP VAICOV20-80053 VALEO186817

OE Numbers — BMW 3411 6764

641

OE Numbers — BMW

34116764641
MakeModelType / Engine YearsCCkWHP
BMW 1 (E81) 120 d 2006 – 2012 1995 145 197
BMW 1 (E81) 116 d 2006 – 2012 1995 66 90
BMW 1 (E81) 118 i 2006 – 2012 1995 95 129
BMW 1 (E81) 116 i 2006 – 2012 1596 85 115
BMW 1 (E81) 120 d 2006 – 2012 1995 120 163
BMW 1 (E81) 130 i 2006 – 2012 2996 195 265
BMW 1 (E81) 118 i 2006 – 2012 1995 105 143
BMW 1 (E81) 120 i 2006 – 2012 1995 125 170
BMW 1 (E81) 118 d 2006 – 2012 1995 105 143
BMW 1 (E81) 120 d 2006 – 2012 1995 130 177
BMW 1 (E81) 123 d 2006 – 2012 1995 150 204
BMW 1 (E81) 116 i 2006 – 2012 1599 90 122
BMW 1 (E81) 120 i 2006 – 2012 1995 115 156
BMW 1 (E81) 116 i 2006 – 2012 1995 90 122
BMW 1 (E81) 116 d 2006 – 2012 1995 85 116
BMW 1 (E81) 130 i 2006 – 2012 2996 190 258
BMW 1 (E81) 118 d 2006 – 2012 1995 100 136
BMW 1 (E81) 120 i 2006 – 2012 1995 120 163
BMW 1 (E81) 118 i 2006 – 2012 1995 100 136
BMW 1 (E87) 116 i 2003 – 2013 1596 85 115
BMW 1 (E87) 116 i 2003 – 2013 1599 90 122
BMW 1 (E87) 116 i 2003 – 2013 1995 90 122
BMW 1 (E87) 118 i 2003 – 2013 1995 95 129
BMW 1 (E87) 118 i 2003 – 2013 1995 100 136
BMW 1 (E87) 118 i 2003 – 2013 1995 105 143
BMW 1 (E87) 120 i 2003 – 2013 1995 110 150
BMW 1 (E87) 120 i 2003 – 2013 1995 115 156
BMW 1 (E87) 120 i 2003 – 2013 1995 120 163
BMW 1 (E87) 120 i 2003 – 2013 1995 125 170
BMW 1 (E87) 130 i 2003 – 2013 2996 190 258
BMW 1 (E87) 130 i 2003 – 2013 2996 195 265
BMW 1 (E87) 116 d 2003 – 2013 1995 85 116
BMW 1 (E87) 118 d 2003 – 2013 1995 90 122
BMW 1 (E87) 118 d 2003 – 2013 1995 100 136
BMW 1 (E87) 118 d 2003 – 2013 1995 105 143
BMW 1 (E87) 120 d 2003 – 2013 1995 120 163
BMW 1 (E87) 123 d 2003 – 2013 1995 150 204
BMW 1 (E87) 120 d 2003 – 2013 1995 110 150
BMW 1 (E87) 120 d 2003 – 2013 1995 115 156
BMW 1 (E87) 120 d 2003 – 2013 1995 125 170
BMW 1 (E87) 118 i 2003 – 2013 1995 125 170
BMW 1 (E87) 120 d 2003 – 2013 1995 130 177
BMW 1 (E87) 116 d 2003 – 2013 1995 66 90
BMW 1 Convertible (E88) 118 i 2007 – 2013 1995 100 136
BMW 1 Convertible (E88) 120 i 2007 – 2013 1995 125 170
BMW 1 Convertible (E88) 125 i 2007 – 2013 2996 160 218
BMW 1 Convertible (E88) 118 i 2007 – 2013 1995 105 143
BMW 1 Convertible (E88) 135 i 2007 – 2013 2979 225 306
BMW 1 Convertible (E88) 120 d 2007 – 2013 1995 130 177
BMW 1 Convertible (E88) 118 d 2007 – 2013 1995 105 143
BMW 1 Convertible (E88) 123 d 2007 – 2013 1995 150 204
BMW 1 Convertible (E88) 120 i 2007 – 2013 1995 120 163
BMW 1 Convertible (E88) 120 d 2007 – 2013 1995 120 163
BMW 1 Convertible (E88) 118 d 2007 – 2013 1995 100 136
BMW 1 Convertible (E88) 128 i 2007 – 2013 2996 172 234
BMW 1 Convertible (E88) 120 i 2007 – 2013 1995 115 156
BMW 1 Convertible (E88) 135 i 2007 – 2013 2979 240 326
BMW 1 Convertible (E88) 120 d 2007 – 2013 1995 145 197
BMW 1 Coupe (E82) M 2006 – 2013 2979 250 340
BMW 1 Coupe (E82) 118 d 2006 – 2013 1995 100 136
BMW 1 Coupe (E82) 135 i 2006 – 2013 2979 225 306
BMW 1 Coupe (E82) 120 d 2006 – 2013 1995 130 177
BMW 1 Coupe (E82) 123 d 2006 – 2013 1995 150 204
BMW 1 Coupe (E82) 125 i 2006 – 2013 2996 160 218
BMW 1 Coupe (E82) 120 d 2006 – 2013 1995 120 163
BMW 1 Coupe (E82) 120 i 2006 – 2013 1995 125 170
BMW 1 Coupe (E82) 118 d 2006 – 2013 1995 105 143
BMW 1 Coupe (E82) 128 i 2006 – 2013 2996 172 234
BMW 1 Coupe (E82) 120 i 2006 – 2013 1995 115 156
BMW 1 Coupe (E82) 120 d 2006 – 2013 1995 145 197
BMW 1 Coupe (E82) 135 i 2006 – 2013 2979 240 326
BMW 3 (E90) 320 d 2004 – 2012 1995 125 170
BMW 3 (E90) 325 i xDrive 2004 – 2012 2996 155 211
BMW 3 (E90) 330 d 2004 – 2012 2993 155 211
BMW 3 (E90) 325 xi 2004 – 2012 2996 160 218
BMW 3 (E90) 335 xi 2004 – 2012 2979 240 326
BMW 3 (E90) 335 i xDrive 2004 – 2012 2979 240 326
BMW 3 (E90) 320 i 2004 – 2012 1995 120 163
BMW 3 (E90) 335 i 2004 – 2012 2979 240 326
BMW 3 (E90) 328 xi 2004 – 2012 2996 172 234
BMW 3 (E90) 330 i 2004 – 2012 2996 200 272
BMW 3 (E90) M3 CRT 2004 – 2012 4361 331 450
BMW 3 (E90) 325 i 2004 – 2012 2996 155 211
BMW 3 (E90) 335 i xDrive 2004 – 2012 2979 224 305
BMW 3 (E90) 335 xi 2004 – 2012 2979 224 305
BMW 3 (E90) 328 i xDrive 2004 – 2012 2996 172 234
BMW 3 (E90) 320 d 2004 – 2012 1995 115 156
BMW 3 (E90) 318 d 2004 – 2012 1995 100 136
BMW 3 (E90) 320 d xDrive 2004 – 2012 1995 120 163
BMW 3 (E90) 320 i 2004 – 2012 1995 110 150
BMW 3 (E90) 325 i 2004 – 2012 2497 160 218
BMW 3 (E90) 330 i 2004 – 2012 2996 190 258
BMW 3 (E90) 320 d 2004 – 2012 1995 120 163
BMW 3 (E90) 318 i 2004 – 2012 1995 95 129
BMW 3 (E90) 318 d 2004 – 2012 1995 90 122
BMW 3 (E90) 330 d 2004 – 2012 2993 170 231
BMW 3 (E90) 325 xi 2004 – 2012 2497 160 218
BMW 3 (E90) 330 xi 2004 – 2012 2996 190 258
BMW 3 (E90) 330 xd 2004 – 2012 2993 170 231
BMW 3 (E90) 320 si 2004 – 2012 1997 127 173
BMW 3 (E90) 335 i 2004 – 2012 2979 225 306
BMW 3 (E90) 335 d 2004 – 2012 2993 210 286
BMW 3 (E90) 320 d 2004 – 2012 1995 110 150
BMW 3 (E90) 325 d 2004 – 2012 2993 145 197
BMW 3 (E90) 318 i 2004 – 2012 1995 105 143
BMW 3 (E90) 318 d 2004 – 2012 1995 105 143
BMW 3 (E90) 335 xi 2004 – 2012 2979 225 306
BMW 3 (E90) 325 i 2004 – 2012 2996 160 218
BMW 3 (E90) 325 xi 2004 – 2012 2996 160 218
BMW 3 (E90) 320 i 2004 – 2012 1995 125 170
BMW 3 (E90) 320 d 2004 – 2012 1995 130 177
BMW 3 (E90) 330 i 2004 – 2012 2996 200 272
BMW 3 (E90) 330 xi 2004 – 2012 2996 200 272
BMW 3 (E90) M3 2004 – 2012 3999 309 420
BMW 3 (E90) 316 i 2004 – 2012 1596 85 115
BMW 3 (E90) 323 i 2004 – 2012 2497 130 177
BMW 3 (E90) 335 i 2004 – 2012 2979 224 305
BMW 3 (E90) 335 i 2004 – 2012 2979 220 299
BMW 3 (E90) 330 d 2004 – 2012 2993 180 245
BMW 3 (E90) 330 d xDrive 2004 – 2012 2993 180 245
BMW 3 (E90) 316 i 2004 – 2012 1599 90 122
BMW 3 (E90) 325 i xDrive 2004 – 2012 2996 160 218
BMW 3 (E90) 330 i xDrive 2004 – 2012 2996 200 272
BMW 3 (E90) 335 i xDrive 2004 – 2012 2979 225 306
BMW 3 (E90) 320 d xDrive 2004 – 2012 1995 130 177
BMW 3 (E90) 316 d 2004 – 2012 1995 85 116
BMW 3 (E90) 320 d 2004 – 2012 1995 135 184
BMW 3 (E90) 320 d xDrive 2004 – 2012 1995 135 184
BMW 3 (E90) 325 d 2004 – 2012 2993 150 204
BMW 3 (E90) 320 i 2004 – 2012 1995 115 156
BMW 3 (E90) 335 d 2004 – 2012 2993 198 269
BMW 3 (E90) 325 i 2004 – 2012 2497 155 211
BMW 3 (E90) 323 i 2004 – 2012 2497 140 190
BMW 3 (E90) 325 i 2004 – 2012 2497 163 222
BMW 3 (E90) 318 i 2004 – 2012 1995 100 136
BMW 3 (E90) 328 i 2004 – 2012 2996 172 234
