Specifications
| Bolt Hole Circle Ø (mm) | 120 |
| Bore Diameter 1 (mm) | 14.5 |
| Centering Diameter (mm) | 75 |
| Drum diameter (mm) | 250 |
| Inner brake drum height (mm) | 47. max. brake drum reboring dimension [mm] 251 |
| Number of Holes 5 | |
| Outer brake drum diameter (mm) | 264 |
| Total brake drum height (mm) | 63 |
Bolt Hole Circle Ø [mm] 120, Bore Diameter 1 [mm] 14,5, Centering Diameter [mm] 75, Drum diameter [mm] 250, Inner brake drum height [mm] 47, max. brake drum reboring dimension [mm] 251, Number of Holes 5, Outer brake drum diameter [mm] 264, Total brake drum height [mm] 63
Fits: BMW
Fits: BMW
Interchangeable Part Numbers
OE Numbers — BMW
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| BMW | 5 (E12) | 520 i/6 | 1972 – 1981 | 1990 | 90 | 122 |
| BMW | 5 (E12) | 520 i | 1972 – 1981 | 1990 | 96 | 131 |
| BMW | 5 (E12) | 520 i | 1972 – 1981 | 1990 | 92 | 125 |
| BMW | 5 (E12) | M535 i | 1972 – 1981 | 3453 | 160 | 218 |
| BMW | 5 (E12) | 518 i | 1972 – 1981 | 1766 | 75 | 102 |
| BMW | 5 (E12) | 530 i | 1972 – 1981 | 2986 | 131 | 178 |
| BMW | 5 (E12) | 528i | 1972 – 1981 | 2788 | 126 | 171 |
| BMW | 5 (E12) | 518 | 1972 – 1981 | 1766 | 66 | 90 |
| BMW | 5 (E12) | 528 i | 1972 – 1981 | 2788 | 135 | 184 |
| BMW | 5 (E12) | 528 i | 1972 – 1981 | 2788 | 130 | 177 |
| BMW | 5 (E12) | 528 | 1972 – 1981 | 2788 | 125 | 170 |
| BMW | 5 (E12) | 528 | 1972 – 1981 | 2788 | 121 | 165 |
| BMW | 5 (E12) | 525 | 1972 – 1981 | 2494 | 110 | 150 |
| BMW | 5 (E12) | 525 | 1972 – 1981 | 2494 | 107 | 145 |
| BMW | 5 (E12) | 520/6 | 1972 – 1981 | 1990 | 90 | 122 |
| BMW | 5 (E12) | 520 | 1972 – 1981 | 1990 | 85 | 115 |
| BMW | 5 (E28) | M535 i | 1981 – 1987 | 3430 | 160 | 218 |
| BMW | 5 (E28) | M5 | 1981 – 1987 | 3453 | 191 | 260 |
| BMW | 5 (E28) | 533 i | 1981 – 1987 | 3210 | 135 | 184 |
| BMW | 5 (E28) | 518 i | 1981 – 1987 | 1766 | 75 | 102 |
| BMW | 5 (E28) | 520 i | 1981 – 1987 | 1990 | 110 | 150 |
| BMW | 5 (E28) | M5 | 1981 – 1987 | 3453 | 210 | 286 |
| BMW | 5 (E28) | 518 | 1981 – 1987 | 1766 | 66 | 90 |
| BMW | 5 (E28) | 518 i | 1981 – 1987 | 1766 | 77 | 105 |
| BMW | 5 (E28) | 520 i | 1981 – 1987 | 1990 | 92 | 125 |
| BMW | 5 (E28) | 520 i | 1981 – 1987 | 1990 | 95 | 129 |
| BMW | 5 (E28) | 524 d | 1981 – 1987 | 2443 | 63 | 86 |
| BMW | 5 (E28) | 524 td | 1981 – 1987 | 2443 | 85 | 115 |
| BMW | 5 (E28) | 525 i | 1981 – 1987 | 2494 | 110 | 150 |
| BMW | 5 (E28) | 525 e | 1981 – 1987 | 2693 | 90 | 122 |
| BMW | 5 (E28) | 525 e | 1981 – 1987 | 2693 | 92 | 125 |
| BMW | 5 (E28) | 525 e | 1981 – 1987 | 2693 | 95 | 129 |
| BMW | 5 (E28) | 528 i | 1981 – 1987 | 2788 | 135 | 184 |
| BMW | 5 (E28) | 535 i, M 535 i | 1981 – 1987 | 3430 | 136 | 185 |
| BMW | 5 (E28) | 535 i, M 535 i | 1981 – 1987 | 3430 | 141 | 192 |
| BMW | 5 (E28) | 535 i | 1981 – 1987 | 3430 | 162 | 220 |
| BMW | 5 (E34) | 518 i | 1987 – 1995 | 1796 | 83 | 113 |
| BMW | 5 (E34) | 525 td | 1987 – 1995 | 2497 | 85 | 115 |
| BMW | 5 (E34) | 518 i | 1987 – 1995 | 1796 | 85 | 115 |
| BMW | 5 (E34) | 540 i V8 | 1987 – 1995 | 3982 | 210 | 286 |
| BMW | 5 (E34) | M5 | 1987 – 1995 | 3795 | 250 | 340 |
| BMW | 5 (E34) | M5 | 1987 – 1995 | 3535 | 232 | 315 |
| BMW | 5 (E34) | 535 i | 1987 – 1995 | 3430 | 155 | 211 |
| BMW | 5 (E34) | 530 i V8 | 1987 – 1995 | 2997 | 160 | 218 |
| BMW | 5 (E34) | 530 i | 1987 – 1995 | 2986 | 138 | 188 |
| BMW | 5 (E34) | 525 tds | 1987 – 1995 | 2497 | 105 | 143 |
| BMW | 5 (E34) | 525 iX 24V | 1987 – 1995 | 2494 | 141 | 192 |
| BMW | 5 (E34) | 525 i 24V | 1987 – 1995 | 2494 | 141 | 192 |
| BMW | 5 (E34) | 525 i | 1987 – 1995 | 2494 | 125 | 170 |
| BMW | 5 (E34) | 524 td | 1987 – 1995 | 2443 | 85 | 115 |
| BMW | 5 (E34) | 520 i 24V | 1987 – 1995 | 1990 | 110 | 150 |
| BMW | 5 (E34) | 520 i | 1987 – 1995 | 1990 | 95 | 129 |
