TRW
Braking System
Brake Drum
Part No.
DB4060
·
SKU
DB4060-TRW
Price on request
Currently out of stock
Get notified when this part is back in stock:
Genuine & OEM parts
Nationwide delivery
Easy returns
Specifications
| Bolt Hole Circle Ø (mm) | 100 |
| Bore Diameter 1 (mm) | 14.8 |
| Centering Diameter (mm) | 54 |
| Drum diameter (mm) | 200 |
| Inner brake drum height (mm) | 47. max. brake drum reboring dimension [mm] 201 |
| Number of Holes 5 |
| Outer brake drum diameter (mm) | 218 |
| Thread Size 2 M6 x 1,0 |
| Total brake drum height (mm) | 67 |
Bolt Hole Circle Ø [mm] 100, Bore Diameter 1 [mm] 14,8, Centering Diameter [mm] 54, Drum diameter [mm] 200, Inner brake drum height [mm] 47, max. brake drum reboring dimension [mm] 201, Number of Holes 5, Outer brake drum diameter [mm] 218, Thread Size 2 M6 x 1,0, Total brake drum height [mm] 67
Interchangeable Part Numbers
A.B.S.2365S
APECDRM9127
BENDIX329081B
Brake ENGINEERINGDR961979
BREMBO14496910
BREMBO14496940
DELPHIBF192
FIRST LINEFBR720
HELLA8DT 355 302-071
HERTH+BUSS JAKOPARTSJ3402009
JURID329081J
NK254507
OMC100460
QH Benelux66171
QUINTON HAZELLBTF170
TEXTAR94018000
TEXTAR98100018001
TRISCAN812013210
OE Numbers — TOYOTA
42431-32010
