Specifications
| Bolt Hole Circle Ø (mm) | 140 |
| Centering Diameter (mm) | 97.1 |
| Drum diameter (mm) | 279 |
| Fitting Position Rear Axle | |
| Inner brake drum height (mm) | 66. max. brake drum reboring dimension [mm] 281 |
| Number of Holes 6 | |
| Outer brake drum diameter (mm) | 322 |
| Thread Size 14.5 | |
| Total brake drum height (mm) | 96 |
Bolt Hole Circle Ø [mm] 140, Centering Diameter [mm] 97,1, Drum diameter [mm] 279, Fitting Position Rear Axle, Inner brake drum height [mm] 66, max. brake drum reboring dimension [mm] 281, Number of Holes 6, Outer brake drum diameter [mm] 322, Thread Size 14.5, Total brake drum height [mm] 96
