Specifications
| Bolt Hole Circle Ø (mm) | 140 |
| Centering Diameter (mm) | 114 |
| Drum diameter (mm) | 320 |
| Fitting Position Rear Axle | |
| Inner brake drum height (mm) | 88. max. brake drum reboring dimension [mm] 321.5 |
| Number of Holes 5 | |
| Outer brake drum diameter (mm) | 370 |
| Thread Size M14 | |
| Total brake drum height (mm) | 129 |
Bolt Hole Circle Ø [mm] 140, Centering Diameter [mm] 114, Drum diameter [mm] 320, Fitting Position Rear Axle, Inner brake drum height [mm] 88, max. brake drum reboring dimension [mm] 321,5, Number of Holes 5, Outer brake drum diameter [mm] 370, Thread Size M14, Total brake drum height [mm] 129
