Specifications
| Bolt Hole Circle Ø (mm) | 208 |
| Centering Diameter (mm) | 165 |
| Drum diameter (mm) | 320 |
| Fitting Position Front Axle | |
| Fitting Position Rear Axle | |
| Inner brake drum height (mm) | 85. max. brake drum reboring dimension [mm] 322 |
| Number of Holes 5 | |
| Outer brake drum diameter (mm) | 373 |
| Thread Size 19.3 | |
| Total brake drum height (mm) | 132 |
Bolt Hole Circle Ø [mm] 208, Centering Diameter [mm] 165, Drum diameter [mm] 320, Fitting Position Front Axle, Fitting Position Rear Axle, Inner brake drum height [mm] 85, max. brake drum reboring dimension [mm] 322, Number of Holes 5, Outer brake drum diameter [mm] 373, Thread Size 19.3, Total brake drum height [mm] 132
