Braking System

Brake Disc

Name: Brake Disc
Brand: TRW
SKU: DF2595S-TRW
Price: 25200.00 PHP
Availability: InStock

Part No. DF2595S · SKU DF2595S-TRW

Front Axle

₱25,200.00

In stock — available to order

Genuine & OEM parts Nationwide delivery Easy returns

Specifications

Bolt Hole Circle Ø (mm)	112
Brake Disc Thickness (mm)	30
Brake Disc Type Vented
Centering Diameter (mm)	67
Colour black
Height (mm)	82
Minimum thickness (mm)	27.4
Number of Holes 5
Outer Diameter (mm)	320
Surface Painted
Test Mark E190R-02C0176/0037
Thread Size 17

Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 30, Brake Disc Type Vented, Centering Diameter [mm] 67, Colour black, Height [mm] 82, Minimum thickness [mm] 27,4, Number of Holes 5, Outer Diameter [mm] 320, Surface Painted, Test Mark E190R-02C0176/0037, Thread Size 17
Fits: MERCEDES-BENZ

Supplier Cross-References

DELPHIBG739 FERODODDF10611 ATE24013001001 JURID561573J BREMBO9872610 TRWDF2595S

Interchangeable Part Numbers

A.P.24437 A.P.24808 APECDSK2001 ATE24113001001 BENDIX561573B BENDIX562023B BLUE PRINTADU174375 BORG & BECKBBD5870S BOSCH0 986 478 527 BRADI1.2825.2.E Brake ENGINEERINGDI955160S BREMBO09.5704.20 BREMBO09872610 CAR142441 CAR142449 CARHPD441 CARHPD449 DBA AustraliaDBA284 DELPHIBS4378 FEBI BILSTEIN08128 FERODODDF1061 FERODODDF1061C-1 FERODODDF629 FERODODDF6291 FIRST LINEFBD511 FREMAXBD0212 FTE9071291 GIRLING6025955 HELLA8DD 355 102-691 HELLA8DD 355 122-212 JURID562023J LEMFÖRDER11067 04 LPRM2421V MAGNETI MARELLI351282520500 MAPCO15785 METELLI230413 MEYLE015 521 2021 MGAD1356 MGAD1357 MINTEXMDC793 NationalNBD404 NK203329 NK313329 PAGID52123 PEX140323 PILENGAV186 QH Benelux57411 QUINTON HAZELL635310 QUINTON HAZELLBDC4378 QUINTON HAZELLBSF4378 REMSA635110 REMYRAD2265C ROULUNDS RUBBERD1646 sbs1815203329 SWAG10908128 TEXTAR92056600 TEXTAR92056603 TEXTAR92056605 TEXTAR98200056601 TRISCAN812023124 TRUCKTEC AUTOMOTIVE0235031 TRUSTINGDF452 TRUSTINGDF456 VAICOV30-80052 VALEO186464 WOKINGP635310 ZIMMERMANN4001421 ZIMMERMANN400142100 ZIMMERMANN400142120 ZIMMERMANN400142150 ZIMMERMANN400142152

OE Numbers — MERCEDES-BENZ

140 421 02 12 140 421 09 12 140 421 10 12 A1404210212 A1404210912 A1404211012

Make	Model	Type / Engine	Years	CC	kW	HP
MERCEDES-BENZ	S-CLASS (W140)	600 SE, SEL (140.056, 140.057)	1991 – 1998	5987	300	408
MERCEDES-BENZ	S-CLASS (W140)	S 420	1991 – 1998	4196	214	291
MERCEDES-BENZ	S-CLASS (W140)	S 320	1991 – 1998	3199	162	220
MERCEDES-BENZ	S-CLASS (W140)	S 300 Turbo-D (140.135)	1991 – 1998	2996	130	177
MERCEDES-BENZ	S-CLASS (W140)	S 350 Turbo-D (140.134)	1991 – 1998	3449	110	150
MERCEDES-BENZ	S-CLASS (W140)	S 600 (140.056, 140.057)	1991 – 1998	5987	290	394
MERCEDES-BENZ	S-CLASS (W140)	500 SE, SEL (140.050, 140.051)	1991 – 1998	4973	240	326
MERCEDES-BENZ	S-CLASS (W140)	S 500 (140.050, 140.051)	1991 – 1998	4973	235	320
MERCEDES-BENZ	S-CLASS (W140)	400 SE, SEL/S420 (140.042, 140.043)	1991 – 1998	4196	210	286
MERCEDES-BENZ	S-CLASS (W140)	S 420 (140.042, 140.043)	1991 – 1998	4196	205	279
MERCEDES-BENZ	S-CLASS (W140)	300 SE, SEL/S320 (140.032, 140.033)	1991 – 1998	3199	170	231
MERCEDES-BENZ	S-CLASS (W140)	300 SE 2.8 (140.028)	1991 – 1998	2799	145	197
MERCEDES-BENZ	S-CLASS (W140)	S 280 (140.028)	1991 – 1998	2799	142	193
MERCEDES-BENZ	S-CLASS Coupe (C140)	500 SEC / CL 500 (140.070)	1992 – 1999	4973	235	320
MERCEDES-BENZ	S-CLASS Coupe (C140)	SEC/CL 600 (140.076)	1992 – 1999	5987	290	394
MERCEDES-BENZ	S-CLASS Coupe (C140)	SEC/CL 420 (140.063)	1992 – 1999	4196	205	279
MERCEDES-BENZ	S-CLASS Coupe (C140)	CL 600	1992 – 1999	5987	270	367
MERCEDES-BENZ	S-CLASS Coupe (C140)	SEC/CL 600	1992 – 1999	5987	300	408
