Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Brake Disc Thickness (mm) | 30 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 65 |
| Colour black | |
| Height (mm) | 49.6 |
| Machining High-carbon | |
| Minimum thickness (mm) | 27 |
| Number of Holes 9 | |
| Outer Diameter (mm) | 335 |
| Rim Hole Number 5 | |
| Surface Painted | |
| SVHC No information available, please contact the manufacturer! | |
| Test Mark E190R-02 C0176/0636 | |
| Thread Size 15,3 | |
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 30, Brake Disc Type Vented, Centering Diameter [mm] 65, Colour black, Height [mm] 49,6, Machining High-carbon, Minimum thickness [mm] 27, Number of Holes 9, Outer Diameter [mm] 335, Rim Hole Number 5, Surface Painted, SVHC No information available, please contact the manufacturer!, Test Mark E190R-02 C0176/0636, Thread Size 15,3
