TRW
Braking System
Brake Disc
Part No.
DF4035
·
SKU
DF4035-TRW
Front Axle
Price on request
Currently out of stock
Get notified when this part is back in stock:
Genuine & OEM parts
Nationwide delivery
Easy returns
Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Brake Disc Thickness (mm) | 22 |
| Brake Disc Type Vented |
| Centering Diameter (mm) | 67 |
| Colour black |
| Height (mm) | 41 |
| Machining High-carbon |
| Minimum thickness (mm) | 19.4 |
| Number of Holes 5 |
| Outer Diameter (mm) | 260 |
| Surface Painted |
| Test Mark E190R-02C0176/0529 |
| Thread Size 13 |
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 22, Brake Disc Type Vented, Centering Diameter [mm] 67, Colour black, Height [mm] 41, Machining High-carbon, Minimum thickness [mm] 19,4, Number of Holes 5, Outer Diameter [mm] 260, Surface Painted, Test Mark E190R-02C0176/0529, Thread Size 13
Fits: MERCEDES-BENZ
Interchangeable Part Numbers
A.B.S.16985
A.P.25070
A.P.X24726
ACDelcoAC2429D
APECDSK813
ATE24012201681
ATE24032201681
BENDIX562049B
BENDIX562049BC
BORG & BECKBBD4110
BOSCH0 986 478 875
BOSCH0 986 BB4 170
BRADI1.2839.2.4
Brake ENGINEERINGDI955818
BREMBO09.7359.10
BREMBO09735920
BREMBO09735921
BREMBO09735976
CAR142430
CARHPD430
DBA AustraliaDBA557
DELPHIBG3395
DELPHIBS4744
DONPCD11192
FEBI BILSTEIN17747
FEBI BILSTEIN22994
FERODODDF1035
FERODODDF10351
FERODODDF1035C
FERODODDF1035C1
FERODODDF1035X
FERODODRF1035
FIRST LINEFBD1063
FTE9072104
FTE9082148
FTE9082545
FTEBS4744HB
GIRLING6040351
HELLA8DD 355 105-981
HELLA8DD 355 105-991
HELLA8DD 355 127-361
INTERBRAKEMR.59.1P
JURID562049J
JURID562049JC
LEMFÖRDER22222 02
LPRM2591V
LPRM2591VR
MAGNETI MARELLI353612839240
MAGNETI MARELLI431602041020
MAPCO15809
METELLI23-0469C
METELLI230469
METZGER25070V
METZGER6110089
MEYLE015 521 2030
MEYLE0155212030PD
MGAD1269
MINTEXMDC1035
NationalNBD920
NK203346
NK313346
OBTEC A/S232325V
OPTIMALBS-5270C
OPTIMALBS-5270
PAGID52155
PAGID52155PRO
PEX140336
PILENGAV284
QH Benelux57796
QUINTON HAZELLBDC4744
QUINTON HAZELLBSF4744
REMSA652710
REMYRAD1236C
ROULUNDS RUBBERD2429
ST-TEMPLIN0311020590
ST-TEMPLIN0311020595
SWAG10922994
TEXTAR92091300
TEXTAR92091303
TEXTAR98200091301
TRISCAN812023141
TRUCKTEC AUTOMOTIVE0235137
TRUSTINGDF839
VAICOV30-80038
VALEO186573
ZIMMERMANN400360200
ZIMMERMANN400360220
ZIMMERMANN400360250
ZIMMERMANN400360252
OE Numbers — MERCEDES-BENZ
168 421 02 12
168 421 08 12
168421081264
A1684210212
A1684210812
A168421081264
| Make | Model | Type / Engine |
Years | CC | kW | HP |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 140 (168.031, 168.131) |
1997 – 2005 |
1397 |
60 |
82 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 160 (168.033, 168.133) |
1997 – 2005 |
1598 |
75 |
102 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 160 CDI (168.007) |
1997 – 2005 |
1689 |
44 |
60 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 170 CDI (168.008) |
1997 – 2005 |
1689 |
66 |
90 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 190 (168.032, 168.132) |
1997 – 2005 |
1898 |
92 |
125 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 160 CDI (168.006) |
1997 – 2005 |
1689 |
55 |
75 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 170 CDI (168.009, 168.109) |
1997 – 2005 |
1689 |
70 |
95 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 140 (168.031, 168.131) |
1997 – 2005 |
1598 |
60 |
82 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 210 (168.035, 168.135) |
1997 – 2005 |
2084 |
103 |
140 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 38 AMG Twin Engine (168.032) |
1997 – 2005 |
1898 |
184 |
250 |
