Specifications
| Bolt Hole Circle Ø (mm) | 120 |
| Brake Disc Thickness (mm) | 28 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 68 |
| Height (mm) | 50.3 |
| Minimum thickness (mm) | 25 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 305 |
| Thread Size 7.1 | |
Bolt Hole Circle Ø [mm] 120, Brake Disc Thickness [mm] 28, Brake Disc Type Vented, Centering Diameter [mm] 68, Height [mm] 50,3, Minimum thickness [mm] 25, Number of Holes 5, Outer Diameter [mm] 305, Thread Size 7.1
