Specifications
| Bolt Hole Circle Ø (mm) | 140 |
| Brake Disc Thickness (mm) | 20.6 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 100 |
| Height (mm) | 56.1 |
| Minimum thickness (mm) | 18.5 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 300 |
| Thread Size 17 | |
Bolt Hole Circle Ø [mm] 140, Brake Disc Thickness [mm] 20,6, Brake Disc Type Vented, Centering Diameter [mm] 100, Height [mm] 56,1, Minimum thickness [mm] 18,5, Number of Holes 5, Outer Diameter [mm] 300, Thread Size 17
