Specifications
| Bolt Hole Circle Ø (mm) | 108 |
| Brake Disc Thickness (mm) | 21 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 68 |
| Height (mm) | 47.6 |
| Minimum thickness (mm) | 19 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 280 |
| Thread Size 12,5 | |
Bolt Hole Circle Ø [mm] 108, Brake Disc Thickness [mm] 21, Brake Disc Type Vented, Centering Diameter [mm] 68, Height [mm] 47,6, Minimum thickness [mm] 19, Number of Holes 5, Outer Diameter [mm] 280, Thread Size 12,5
