TRW
Braking System
Brake Disc
Part No.
DF4322
·
SKU
DF4322-TRW
Front Axle
₱14,100.00
In stock — available to order
Genuine & OEM parts
Nationwide delivery
Easy returns
Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Brake Disc Thickness (mm) | 22 |
| Brake Disc Type Vented |
| Centering Diameter (mm) | 67 |
| Colour black |
| Height (mm) | 38.5 |
| Minimum thickness (mm) | 19.4 |
| Number of Holes 5 |
| Outer Diameter (mm) | 276 |
| Surface Painted |
| Test Mark E190R-02C0176/0569 |
| Thread Size 13,25 |
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 22, Brake Disc Type Vented, Centering Diameter [mm] 67, Colour black, Height [mm] 38,5, Minimum thickness [mm] 19,4, Number of Holes 5, Outer Diameter [mm] 276, Surface Painted, Test Mark E190R-02C0176/0569, Thread Size 13,25
Fits: MERCEDES-BENZ
Supplier Cross-References
ZIMMERMANN400363300
FERODODDF11731
HELLA PAGID355110201
JURID562245J
TRWDF4322
HELLA8DD355110201
Interchangeable Part Numbers
A.B.S.17365
APECDSK2094
ATE24012202081
BENDIX562245B
BENDIX562245BC
BORG & BECKBBD4286
BOSCH0 986 478 474
BOSCH0 986 AB5 677
Brake ENGINEERINGDI956038
BREMBO09.8519.10
BREMBO09851911
CAR142427
CARHPD427
DBA AustraliaDBA558
DELPHIBG3829
FEBI BILSTEIN22995
FEBI BILSTEIN22996
FERODODDF1173
FERODODDF1173X
FERODODRF1173
FIRST LINEFBD1287
FREMAXBD-0612
FTE9072373
FTE9082283
FTEBS5168
FTEBS5168B
HELLA8DD 355 106-921
HELLA8DD 355 106-931
HELLA8DD 355 110-211
JURID562245JC
LEMFÖRDER35874 01
LPRM2701V
MAGNETI MARELLI351285720500
METELLI230759
METELLI230759C
METZGER24816
METZGER24816V
MEYLE015 521 1057
MEYLE015 521 2092
MEYLE0155212092PD
MGAD1414
MINTEXMDC1421
NationalNBD1051
NK2033148
NK203370
NK3133148
NK313370
OPEN PARTSBDA2054.20
OPEN PARTSBDR2054.20
OPEN PARTSBDRS2054.25
OPTIMALBS-7410C
OPTIMALBS-7410
OPTIMALBS-7832C
OPTIMALBS-7832
PAGID50273
PAGID50273PRO
PAGID54244
PAGID54244PRO
PEX140852
PILENGAV913
QH Benelux57912
QUINTON HAZELLBDC5168
QUINTON HAZELLBSF5168
REMSA685910
REMYRAD2238C
sbs1815203370
sbs1815313370
SWAG10922995
SWAG10922996
TEXTAR92099600
TEXTAR92099603
TEXTAR92124400
TEXTAR92124403
TRISCAN8120 23171C
TRISCAN812023171
TRUSTINGDF968
VALEO186783
ZIMMERMANN400361000
ZIMMERMANN400361050
ZIMMERMANN400361052
ZIMMERMANN400363320
OE Numbers — MERCEDES-BENZ
168 421 06 12
168 421 07 12
A1684210612
A1684210712
| Make | Model | Type / Engine |
Years | CC | kW | HP |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 140 (168.031, 168.131) |
1997 – 2005 |
1397 |
60 |
82 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 160 (168.033, 168.133) |
1997 – 2005 |
1598 |
75 |
102 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 160 CDI (168.007) |
1997 – 2005 |
1689 |
44 |
60 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 170 CDI (168.008) |
1997 – 2005 |
1689 |
66 |
90 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 190 (168.032, 168.132) |
1997 – 2005 |
1898 |
92 |
125 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 160 CDI (168.006) |
1997 – 2005 |
1689 |
55 |
75 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 170 CDI (168.009, 168.109) |
1997 – 2005 |
1689 |
70 |
95 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 140 (168.031, 168.131) |
1997 – 2005 |
1598 |
60 |
82 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 210 (168.035, 168.135) |
1997 – 2005 |
2084 |
103 |
140 |
| MERCEDES-BENZ |
A-CLASS (W168) |
A 38 AMG Twin Engine (168.032) |
1997 – 2005 |
1898 |
184 |
250 |
