Brake Disc
Brake Disc 1 Brake Disc 2
Braking System

Brake Disc

Part No. DF4358 · SKU DF4358-TRW
Front Axle
Price on request
Currently out of stock

Get notified when this part is back in stock:

Genuine & OEM parts Nationwide delivery Easy returns

Specifications

Bolt Hole Circle Ø (mm)112
Brake Disc Thickness (mm)30
Brake Disc Type Vented
Centering Diameter (mm)67.5
Height (mm)59.9
Machining High-carbon
Minimum thickness (mm)28
Number of Holes 5
Outer Diameter (mm)321
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 30, Brake Disc Type Vented, Centering Diameter [mm] 67,5, Height [mm] 59,9, Machining High-carbon, Minimum thickness [mm] 28, Number of Holes 5, Outer Diameter [mm] 321
Fits: AUDI, AUDI (FAW)

Interchangeable Part Numbers

A.B.S.17624 ATE24013001751 ATE24033001751 BOSCH0 986 479 300 BOSCH0 986 AB6 113 BOSCH0 986 T16 113 BREMBO09.C895.11 BREMBO09.C895.1X BREMBO09953411 DELPHIBG3939 FEBI BILSTEIN26647 FERODODDF1277C FERODODDF1277C-D FERODODDF1277C1 FERODODDF1277DSL-1-D FERODODDF1277DSR-1-D FERODODDF1277X FIRST LINEFBD1559 GIRLING6043581 HELLA8DD 355 111-141 HELLA8DD 355 122-722 HELLA8DD 355 128-301 ICER78BD4085-2 KAWE6807 10 LPRA1019V LPRA1019VR MAGNETI MARELLI360406002400 MAPCO25876 METELLI230916C MEYLE115 521 1098/PD MEYLE115 521 1098 MEYLE1835211098PD OPTIMALBS-7536C OPTIMALBS-7536HC OPTIMALBS-7536 QUINTON HAZELLBDC5545 REMYRAD1381C SWAG30221196 SWAG32926647 TEXTAR92132300 TEXTAR92132305 TRUSTINGDF070 VALEO197199 VALEO197388 VALEO297199 VALEO672541 WOKINGD6807.10 ZIMMERMANN100.3318.00 ZIMMERMANN100.3318.52

OE Numbers — AUDI

4F0 615 301 E
MakeModelType / Engine YearsCCkWHP
AUDI A6 Allroad C6 (4FH) 2.7 TDI quattro 2006 – 2011 2698 120 163
AUDI A6 Allroad C6 (4FH) 2.7 TDI quattro 2006 – 2011 2698 140 190
AUDI A6 Allroad C6 (4FH) 3.2 FSI quattro 2006 – 2011 3123 188 255
AUDI A6 Allroad C6 (4FH) 4.2 FSI quattro 2006 – 2011 4163 257 350
AUDI A6 Allroad C6 (4FH) 3.0 TDI quattro 2006 – 2011 2967 176 240
AUDI A6 Allroad C6 (4FH) 3.0 TDI quattro 2006 – 2011 2967 171 233
AUDI A6 Allroad C6 (4FH) 2.7 TDI quattro 2006 – 2011 2698 132 180
AUDI A6 Allroad C6 (4FH) 3.0 TDI quattro 2006 – 2011 2967 155 211
AUDI A6 Allroad C6 (4FH) 3.0 TFSI quattro 2006 – 2011 2995 213 290
AUDI A6 C6 (4F2) 3.0 TDI quattro 2004 – 2011 2967 176 240
AUDI A6 C6 (4F2) 2.8 FSI 2004 – 2011 2773 162 220
AUDI A6 C6 (4F2) 2.8 FSI quattro 2004 – 2011 2773 162 220
AUDI A6 C6 (4F2) 2.7 TDI quattro 2004 – 2011 2698 132 180
AUDI A6 C6 (4F2) 2.8 FSI quattro 2004 – 2011 2773 140 190
AUDI A6 C6 (4F2) 2.8 FSI 2004 – 2011 2773 140 190
AUDI A6 C6 (4F2) 2.0 TFSI 2004 – 2011 1984 125 170
AUDI A6 C6 (4F2) 2.7 TDI quattro 2004 – 2011 2698 140 190
AUDI A6 C6 (4F2) 2.0 TDI 2004 – 2011 1968 100 136
AUDI A6 C6 (4F2) 2.7 TDI 2004 – 2011 2698 140 190
AUDI A6 C6 (4F2) 2.7 TDI quattro 2004 – 2011 2698 120 163
AUDI A6 C6 (4F2) 2.0 TDI 2004 – 2011 1968 125 170
AUDI A6 C6 (4F2) S6 quattro 2004 – 2011 5204 320 435
AUDI A6 C6 (4F2) RS6 quattro 2004 – 2011 4991 426 580
AUDI A6 C6 (4F2) 3.2 FSI quattro 2004 – 2011 3123 183 249
AUDI A6 C6 (4F2) 3.0 quattro 2004 – 2011 2976 160 218
AUDI A6 C6 (4F2) 2.8 FSI quattro 2004 – 2011 2773 154 210
AUDI A6 C6 (4F2) 2.8 FSI 2004 – 2011 2773 154 210
AUDI A6 C6 (4F2) 4.2 FSI quattro 2004 – 2011 4163 257 350
AUDI A6 C6 (4F2) 3.0 TDI quattro 2004 – 2011 2967 171 233
AUDI A6 C6 (4F2) 2.0 TDI 2004 – 2011 1968 89 121
AUDI A6 C6 (4F2) 3.0 2004 – 2011 2976 160 218
AUDI A6 C6 (4F2) 3.0 TDI quattro 2004 – 2011 2967 155 211
AUDI A6 C6 (4F2) 3.0 TFSI quattro 2004 – 2011 2995 220 299
AUDI A6 C6 (4F2) 3.2 FSI 2004 – 2011 3197 195 265
AUDI A6 C6 (4F2) 2.8 V6 2004 – 2011 2771 142 193
AUDI A6 C6 (4F2) 2.0 TDI 2004 – 2011 1968 120 163
AUDI A6 C6 (4F2) 2.4 2004 – 2011 2393 130 177
AUDI A6 C6 (4F2) 3.2 FSI 2004 – 2011 3123 188 255
AUDI A6 C6 (4F2) 3.2 FSI quattro 2004 – 2011 3123 188 255
AUDI A6 C6 (4F2) 2.0 TDI 2004 – 2011 1968 103 140
AUDI A6 C6 (4F2) 4.2 quattro 2004 – 2011 4163 246 335
AUDI A6 C6 (4F2) 3.0 TDI quattro 2004 – 2011 2967 165 225
AUDI A6 C6 (4F2) 2.7 TDI 2004 – 2011 2698 132 180
AUDI A6 C6 (4F2) 3.0 TFSI quattro 2004 – 2011 2995 213 290
AUDI A6 C6 (4F2) 2.4 quattro 2004 – 2011 2393 130 177
AUDI A6 C6 (4F2) 2.7 TDI 2004 – 2011 2698 120 163
AUDI A6 C6 Avant (4F5) RS6 quattro 2004 – 2011 4991 426 580
AUDI A6 C6 Avant (4F5) 2.0 TDI 2004 – 2011 1968 125 170
AUDI A6 C6 Avant (4F5) 2.7 TDI 2004 – 2011 2698 140 190
AUDI A6 C6 Avant (4F5) 2.0 TDI 2004 – 2011 1968 120 163
AUDI A6 C6 Avant (4F5) 3.0 2004 – 2011 2976 160 218
AUDI A6 C6 Avant (4F5) 2.7 TDI quattro 2004 – 2011 2698 140 190
AUDI A6 C6 Avant (4F5) 2.8 FSI quattro 2004 – 2011 2773 154 210
AUDI A6 C6 Avant (4F5) 2.8 FSI 2004 – 2011 2773 140 190
AUDI A6 C6 Avant (4F5) 2.8 FSI 2004 – 2011 2773 162 220
AUDI A6 C6 Avant (4F5) 2.8 FSI quattro 2004 – 2011 2773 140 190
AUDI A6 C6 Avant (4F5) 2.8 FSI quattro 2004 – 2011 2773 162 220
AUDI A6 C6 Avant (4F5) 3.0 TDI quattro 2004 – 2011 2967 176 240
AUDI A6 C6 Avant (4F5) 3.0 TFSI quattro 2004 – 2011 2995 213 290
AUDI A6 C6 Avant (4F5) 3.0 TFSI quattro 2004 – 2011 2995 220 299
AUDI A6 C6 Avant (4F5) 2.0 TDI 2004 – 2011 1968 89 121
AUDI A6 C6 Avant (4F5) 2.7 TDI quattro 2004 – 2011 2698 120 163
AUDI A6 C6 Avant (4F5) 3.0 quattro 2004 – 2011 2976 160 218
AUDI A6 C6 Avant (4F5) 3.0 TDI quattro 2004 – 2011 2967 155 211
AUDI A6 C6 Avant (4F5) 2.4 quattro 2004 – 2011 2393 130 177
AUDI A6 C6 Avant (4F5) 2.7 TDI 2004 – 2011 2698 132 180
AUDI A6 C6 Avant (4F5) 2.7 TDI quattro 2004 – 2011 2698 132 180
AUDI A6 C6 Avant (4F5) 2.4 2004 – 2011 2393 130 177
AUDI A6 C6 Avant (4F5) 4.2 quattro 2004 – 2011 4163 246 335
AUDI A6 C6 Avant (4F5) 2.0 TFSI 2004 – 2011 1984 125 170
AUDI A6 C6 Avant (4F5) 2.0 TDI 2004 – 2011 1968 100 136
AUDI A6 C6 Avant (4F5) S6 quattro 2004 – 2011 5204 320 435
AUDI A6 C6 Avant (4F5) 3.2 FSI quattro 2004 – 2011 3123 188 255
AUDI A6 C6 Avant (4F5) 4.2 FSI quattro 2004 – 2011 4163 257 350
AUDI A6 C6 Avant (4F5) 3.0 TDI quattro 2004 – 2011 2967 171 233
AUDI A6 C6 Avant (4F5) 3.2 FSI 2004 – 2011 3123 188 255
AUDI A6 C6 Avant (4F5) 3.0 TDI quattro 2004 – 2011 2967 165 225
AUDI A6 C6 Avant (4F5) 2.7 TDI 2004 – 2011 2698 120 163
AUDI A6 C6 Avant (4F5) 2.8 FSI 2004 – 2011 2773 154 210
AUDI A6 C6 Avant (4F5) 2.0 TDI 2004 – 2011 1968 103 140
AUDI A8 D3 (4E2, 4E8) 4.0 TDI quattro 2002 – 2010 3936 202 275
AUDI A8 D3 (4E2, 4E8) 6.0 W12 quattro 2002 – 2010 5998 331 450
AUDI A8 D3 (4E2, 4E8) 3.0 2002 – 2010 2976 162 220
AUDI A8 D3 (4E2, 4E8) 3.2 FSI 2002 – 2010 3123 191 260
AUDI A8 D3 (4E2, 4E8) 3.7 quattro 2002 – 2010 3697 206 280
AUDI A8 D3 (4E2, 4E8) 2.8 FSI 2002 – 2010 2773 170 231
AUDI A8 D3 (4E2, 4E8) 4.2 quattro 2002 – 2010 4172 224 305
AUDI A8 D3 (4E2, 4E8) S 8 quattro 2002 – 2010 4172 268 364
AUDI A8 D3 (4E2, 4E8) 4.2 quattro 2002 – 2010 4172 246 335
AUDI A8 D3 (4E2, 4E8) 3.0 quattro 2002 – 2010 2976 162 220
AUDI A8 D3 (4E2, 4E8) 3.0 TDI quattro 2002 – 2010 2967 171 233
AUDI A8 D3 (4E2, 4E8) 3.2 FSI quattro 2002 – 2010 3123 191 260
AUDI A8 D3 (4E2, 4E8) 4.2 TDI quattro 2002 – 2010 4134 235 320
AUDI A8 D3 (4E2, 4E8) 3.0 2002 – 2010 2976 160 218
AUDI A8 D3 (4E2, 4E8) 3.0 TDI quattro 2002 – 2010 2967 155 211
AUDI A8 D3 (4E2, 4E8) S8 quattro 2002 – 2010 5204 331 450
AUDI A8 D3 (4E2, 4E8) 4.2 TDI quattro 2002 – 2010 4134 240 326
AUDI A8 D3 (4E2, 4E8) 2.8 FSI 2002 – 2010 2773 154 210
AUDI A8 D3 (4E2, 4E8) 4.2 FSI quattro 2002 – 2010 4163 257 350
AUDI A8 D3 (4E2, 4E8) 3.0 quattro 2002 – 2010 2976 160 218
