Specifications
| Bolt Hole Circle Ø (mm) | 114.3 |
| Brake Disc Thickness (mm) | 27.9 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 62 |
| Height (mm) | 49.4 |
| Minimum thickness (mm) | 26 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 275 |
| Thread Size 14.6 | |
Bolt Hole Circle Ø [mm] 114,3, Brake Disc Thickness [mm] 27,9, Brake Disc Type Vented, Centering Diameter [mm] 62, Height [mm] 49,4, Minimum thickness [mm] 26, Number of Holes 5, Outer Diameter [mm] 275, Thread Size 14.6
