Brake Disc
Brake Disc 1 Brake Disc 2
Braking System

Brake Disc

Part No. DF4453 · SKU DF4453-TRW
Rear Axle
Price on request
Currently out of stock

Get notified when this part is back in stock:

Genuine & OEM parts Nationwide delivery Easy returns

Specifications

Bolt Hole Circle Ø (mm)112
Brake Disc Thickness (mm)8
Brake Disc Type solid
Centering Diameter (mm)67
Colour black
Drum diameter (mm)164
Height (mm)57.3
Minimum thickness (mm)7.3
Number of Holes 5
Outer Diameter (mm)258
Surface Painted
Test Mark E190R-02C0204/0283
Thread Size 14,8
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 8, Brake Disc Type solid, Centering Diameter [mm] 67, Colour black, Drum diameter [mm] 164, Height [mm] 57,3, Minimum thickness [mm] 7,3, Number of Holes 5, Outer Diameter [mm] 258, Surface Painted, Test Mark E190R-02C0204/0283, Thread Size 14,8
Fits: MERCEDES-BENZ

Interchangeable Part Numbers

A.B.S.17645 A.P.14855 APECDSK2300 ATE24010801131 ATE24030801131 BENDIX562274B BENDIX562274BC BORG & BECKBBD4487 BOSCH 0 986 479235 BOSCH0986479235 Brake ENGINEERINGDI956513 BREMBO08.9580.10 BREMBO08958011 BREMBO8958010 CAR1421169 CARHPD1169 DBA AustraliaDBA2693E DELPHIBG3910 DELPHIBG3910C DELPHIBG3910C-18B1 FEBI BILSTEIN24750 FERODODDF1258 FERODODDF12581 FERODODDF1258C FERODODDF1258C-D FERODODDF1258C1 FERODODDF1258X FIRST LINEFBD1535 FREMAXBD-0119 FTE9072095 FTE9082070 FTEBS5439 FTEBS5439B HELLA 8DD 355111-091 HELLA8DD355111091 HELLA 8DD 355111-101 HELLA8DD355111101 Hi-QSD5425 JURID562274J JURID562274JC LEMFÖRDER 3084001 LEMFÖRDER3084001 LPRM2003P LPRM2003PR MAGNETI MARELLI351286950500 MAGNETI MARELLI360704022300 MAPCO25802 METELLI230833C METZGER14855V MEYLE 015 5232079/PD MEYLE0155232079PD MEYLE 015 5232079 MEYLE0155232079 MEYLE0155230027 MEYLE0155230027PD MGAD1539 MINTEXMDC1846 MINTEXMDC1846C NK203374 NK313374 OPTIMALBS-7812C OPTIMALBS-7812 PAGID54321 PAGID54321PRO PEX140824 QH Benelux58294 QUINTON HAZELLBDC5439 QUINTON HAZELLBSF5439 REMSA6106500 REMYRAD1074C ST-TEMPLIN0311020900 ST-TEMPLIN0311020905 SWAG10924750 TEXTAR92132100 TEXTAR92132103 TEXTAR92132105 TEXTAR98200132101 TRISCAN 812023174C TRISCAN812023174C TRISCAN812023174 TRUCKTEC AUTOMOTIVE0235140 TRUSTINGDF1497 VALEO197036 ZIMMERMANN400.3644.00 ZIMMERMANN400364420

OE Numbers — MERCEDES-BENZ 169 423 03

12

OE Numbers — MERCEDES-BENZ

1694230312 1694230912 A1694230312 A1694230912
MakeModelType / Engine YearsCCkWHP
MERCEDES-BENZ A-CLASS (W169) A 200 CDI (169.308, 169.008) 2004 – 2012 1991 100 136
MERCEDES-BENZ A-CLASS (W169) A 170 (169.032, 169.332) 2004 – 2012 1699 85 116
MERCEDES-BENZ A-CLASS (W169) A 150 (169.031, 169.331) 2004 – 2012 1498 70 95
MERCEDES-BENZ A-CLASS (W169) A 200 (169.033, 169.333) 2004 – 2012 2034 100 136
MERCEDES-BENZ A-CLASS (W169) A 160 CDI (169.006, 169.306) 2004 – 2012 1991 60 82
MERCEDES-BENZ A-CLASS (W169) A 180 CDI (169.007, 169.307) 2004 – 2012 1991 80 109
MERCEDES-BENZ A-CLASS (W169) A 200 CDI (169.008, 169.308) 2004 – 2012 1991 103 140
MERCEDES-BENZ A-CLASS (W169) E-CELL (169.090) 2004 – 2012 — 50 68
MERCEDES-BENZ A-CLASS (W169) A 180 (169.032, 169.332) 2004 – 2012 1699 85 116
MERCEDES-BENZ A-CLASS (W169) A 200 TURBO (169.034, 169.334) 2004 – 2012 2034 142 193
MERCEDES-BENZ A-CLASS (W169) A 160 (169.031, 169.331) 2004 – 2012 1498 70 95
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 200 2005 – 2011 2034 155 211
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 200 CDI (245.208) 2005 – 2011 1991 100 136
MERCEDES-BENZ B-CLASS Sports Tourer (W245) F-CELL (242.890) 2005 – 2011 — 100 136
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 180 (245.232) 2005 – 2011 1699 85 116
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 160 (245.231) 2005 – 2011 1498 70 95
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 180 NGT (245.233) 2005 – 2011 2034 85 116
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 170 NGT (245.233) 2005 – 2011 2034 85 116
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 150 (245.231) 2005 – 2011 1498 70 95
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 200 TURBO (245.234) 2005 – 2011 2034 142 193
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 200 (245.233) 2005 – 2011 2034 100 136
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 170 (245.232) 2005 – 2011 1699 85 116
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 200 CDI (245.208) 2005 – 2011 1991 103 140
MERCEDES-BENZ B-CLASS Sports Tourer (W245) B 180 CDI (245.207) 2005 – 2011 1991 80 109
