Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Brake Disc Thickness (mm) | 32 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 67 |
| Colour black | |
| Height (mm) | 54 |
| Machining High-carbon | |
| Minimum thickness (mm) | 29.4 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 330 |
| Surface Painted | |
| Test Mark E190R- 02 C0176/0556 | |
| Thread Size 15,5 | |
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 32, Brake Disc Type Vented, Centering Diameter [mm] 67, Colour black, Height [mm] 54, Machining High-carbon, Minimum thickness [mm] 29,4, Number of Holes 5, Outer Diameter [mm] 330, Surface Painted, Test Mark E190R- 02 C0176/0556, Thread Size 15,5
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Supplier Cross-References
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | M-CLASS (W164) | ML 350 CDI 4-matic (164.125, 164.124) | 2005 – 2012 | 2987 | 170 | 231 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 300 CDI 4-matic (164.120) | 2005 – 2012 | 2987 | 140 | 190 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 350 CDI 4-matic (164.122) | 2005 – 2012 | 2987 | 165 | 224 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 500 4-matic (164.175) | 2005 – 2012 | 4966 | 218 | 296 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 320 CDI 4-matic | 2005 – 2012 | 2987 | 160 | 218 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 350 CDI 4-matic | 2005 – 2012 | 2987 | 190 | 258 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 350 CDI 4-matic | 2005 – 2012 | 2987 | 157 | 214 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 500 4-matic (164.172) | 2005 – 2012 | 5461 | 285 | 388 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 350 CDI 4-matic (164.125, 164.124) | 2005 – 2012 | 2987 | 155 | 211 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 450 CDI 4-matic (164.128) | 2005 – 2012 | 3996 | 225 | 306 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 300 CDI 4-matic (164.121) | 2005 – 2012 | 2987 | 150 | 204 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 300 4-matic (164.182) | 2005 – 2012 | 2996 | 170 | 231 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 420 CDI 4-matic (164.128) | 2005 – 2012 | 3996 | 225 | 306 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 320 CDI 4-matic (164.124, 164.125, 164.122) | 2005 – 2012 | 2987 | 155 | 211 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 63 AMG 4-matic (164.177) | 2005 – 2012 | 6208 | 375 | 510 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 350 (164.156) | 2005 – 2012 | 3498 | 200 | 272 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 63 AMG 4-matic (164.177) | 2005 – 2012 | 6208 | 375 | 510 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 320 CDI 4-matic (164.122) | 2005 – 2012 | 2987 | 165 | 224 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 280 CDI 4-matic (164.120) | 2005 – 2012 | 2987 | 140 | 190 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 500 4-matic (164.175) | 2005 – 2012 | 4966 | 225 | 306 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 350 4-matic (164.186) | 2005 – 2012 | 3498 | 200 | 272 |
| MERCEDES-BENZ | M-CLASS (W164) | ML 450 Hybrid 4-matic (164.195) | 2005 – 2012 | 3498 | 250 | 340 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 320 CDI 4-matic (251.125) | 2005 – 2017 | 2987 | 155 | 211 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 320 CDI 4-matic | 2005 – 2017 | 2987 | 157 | 214 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 320 CDI 4-matic | 2005 – 2017 | 2987 | 160 | 218 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 350 CDI 4-matic | 2005 – 2017 | 2987 | 157 | 214 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 63 AMG 4-matic (251.077, 251.177) | 2005 – 2017 | 6208 | 375 | 510 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 400 4-matic (251.166) | 2005 – 2017 | 2996 | 245 | 333 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 320 4-matic (251.163) | 2005 – 2017 | 2996 | 200 | 272 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 300 (251.154) | 2005 – 2017 | 2996 | 180 | 245 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 300 4-matic (251.062) | 2005 – 2017 | 2996 | 170 | 231 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 350 CDI 4-matic (251.023, 251.123) | 2005 – 2017 | 2987 | 195 | 265 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 500 4-matic (251.072, 251.172) | 2005 – 2017 | 5461 | 285 | 388 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 350 CGI 4-matic (251.057, 251.157) | 2005 – 2017 | 3498 | 225 | 306 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 350 4-matic (251.065, 251.165) | 2005 – 2017 | 3498 | 200 | 272 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 500 4-matic (251.075, 251.175) | 2005 – 2017 | 4966 | 225 | 306 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 320 CDI 4-matic (251.022, 251.122) | 2005 – 2017 | 2987 | 165 | 224 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 280 CDI 4-matic (251.020) | 2005 – 2017 | 2987 | 140 | 190 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 63 AMG 4-matic (251.077, 251.177) | 2005 – 2017 | 6208 | 375 | 510 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 280 (251.054, 251.154) | 2005 – 2017 | 2996 | 170 | 231 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 350 (251.056, 251.156) | 2005 – 2017 | 3498 | 200 | 272 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 500 4-matic | 2005 – 2017 | 4966 | 218 | 296 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 280 CDI (251.121, 251.026, 251.126) | 2005 – 2017 | 2987 | 140 | 190 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 280 4-matic (251.062) | 2005 – 2017 | 2996 | 170 | 231 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 300 CDI (251.021, 251.121, 251.026, 251.126) | 2005 – 2017 | 2987 | 140 | 190 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 300 CDI 4-matic (251.020) | 2005 – 2017 | 2987 | 140 | 190 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 350 CDI 4-matic (251.022, 251.122) | 2005 – 2017 | 2987 | 165 | 224 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 350 CDI 4-matic (251.124, 251.125) | 2005 – 2017 | 2987 | 155 | 211 |
| MERCEDES-BENZ | R-CLASS (W251, V251) | R 300 (251.054, 251.154) | 2005 – 2017 | 2996 | 170 | 231 |
