Specifications
| Bolt Hole Circle Ø (mm) | 114.3 |
| Brake Disc Thickness (mm) | 10 |
| Brake Disc Type solid | |
| Centering Diameter (mm) | 62 |
| Colour black | |
| Height (mm) | 66.7 |
| Machining High-carbon | |
| Minimum thickness (mm) | 8.4 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 267 |
| Surface Painted | |
| Test Mark E1 90R-02 C0190/0535 | |
| Thread Size 14,5 | |
Bolt Hole Circle Ø [mm] 114,3, Brake Disc Thickness [mm] 10, Brake Disc Type solid, Centering Diameter [mm] 62, Colour black, Height [mm] 66,7, Machining High-carbon, Minimum thickness [mm] 8,4, Number of Holes 5, Outer Diameter [mm] 267, Surface Painted, Test Mark E1 90R-02 C0190/0535, Thread Size 14,5
