Specifications
| Bolt Hole Circle Ø (mm) | 108 |
| Brake Disc Thickness (mm) | 28.1 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 68.1 |
| Fitting Position Rear Axle | |
| Height (mm) | 50.5 |
| Minimum thickness (mm) | 25 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 305 |
Bolt Hole Circle Ø [mm] 108, Brake Disc Thickness [mm] 28,1, Brake Disc Type Vented, Centering Diameter [mm] 68,1, Fitting Position Rear Axle, Height [mm] 50,5, Minimum thickness [mm] 25, Number of Holes 5, Outer Diameter [mm] 305
