Specifications
Bolt Hole Circle Ø (mm)
335
Bore Diameter (mm)
23
Brake Disc Thickness (mm)
45
Brake Disc Type Vented
Height (mm)
170
Minimum thickness (mm)
40
Number of Holes 10
Outer Diameter (mm)
377
Test Mark E1190R02C01009/22779
Test Mark E1190R02C01434/38116
Bolt Hole Circle Ø [mm] 335, Bore Diameter [mm] 23, Brake Disc Thickness [mm] 45, Brake Disc Type Vented, Height [mm] 170, Minimum thickness [mm] 40, Number of Holes 10, Outer Diameter [mm] 377, Test Mark E1190R02C01009/22779, Test Mark E1190R02C01434/38116
