Specifications
| Bolt Hole Circle Ø (mm) | 275 |
| Bore Diameter (mm) | 23.1 |
| Brake Disc Thickness (mm) | 45 |
| Brake Disc Type Vented | |
| Height (mm) | 159.5 |
| Number of Holes 8 | |
| Outer Diameter (mm) | 376 |
| Test Mark E1190R02C01434/38116 | |
Bolt Hole Circle Ø [mm] 275, Bore Diameter [mm] 23,1, Brake Disc Thickness [mm] 45, Brake Disc Type Vented, Height [mm] 159,5, Number of Holes 8, Outer Diameter [mm] 376, Test Mark E1190R02C01434/38116
