Brake Disc
Brake Disc 1 Brake Disc 2
Braking System

Brake Disc

Part No. DF6110 · SKU DF6110-TRW
Front Axle
Price on request
Currently out of stock

Get notified when this part is back in stock:

Genuine & OEM parts Nationwide delivery Easy returns

Specifications

Bolt Hole Circle Ø (mm)108
Brake Disc Thickness (mm)24
Brake Disc Type Vented
Centering Diameter (mm)61
Colour black
Height (mm)43.9
Minimum thickness (mm)21.8
Number of Holes 5
Outer Diameter (mm)280
Surface Painted
Test Mark E1 90R-02 C0185/0659
Thread Size 15,7
Bolt Hole Circle Ø [mm] 108, Brake Disc Thickness [mm] 24, Brake Disc Type Vented, Centering Diameter [mm] 61, Colour black, Height [mm] 43,9, Minimum thickness [mm] 21,8, Number of Holes 5, Outer Diameter [mm] 280, Surface Painted, Test Mark E1 90R-02 C0185/0659, Thread Size 15,7
Fits: MERCEDES-BENZ, NISSAN, RENAULT

Interchangeable Part Numbers

A.B.S.09.A727.21 A.P.25264 A.P. 25264V A.P.25264V ATE24012402221 BENDIX562730BC BLUE PRINTADR164306 BORG & BECKBBD5163 BOSCH 0 986 479555 BOSCH0986479555 BOSCH 0 986 479S66 BOSCH0986479S66 Brake ENGINEERINGDI956872 BREMBO09A72720 CAR1421497 CIFAM153355 DELPHIBG4317 DELPHIBG4317C FERODODDF1733 FERODODDF17331 FERODODDF1733C FERODODDF1733C1 fri.tech.1088230 FTE9071033 FTE9081217 FTEBS7259 FTEBS7259B HELLA 8DD 355116-451 HELLA8DD355116451 JURID562730JC LPRR1039V LPRR1039VR MAGNETI MARELLI360704024200 MAPCO25126 METELLI231341C METELLI530355 METZGER6110003 MEYLE 16-15 5210021/PD MEYLE16155210021PD MEYLE 16-15 5210021 MEYLE16155210021 MEYLE16155210042 MEYLE16155210042PD MGAD1805 MINTEXMDC2238 NK203974 NK313974 Omnicraft2134443 PAGID55024 PILENGAV798 REMSA6141110 sbs1815203974 ST-TEMPLIN0311083890 TEXTAR92202400 TEXTAR92202403 TRISCAN812025158 TRISCAN812025158C TRUCKTEC AUTOMOTIVE0235443 TRUSTING088230 TRUSTINGDF1458 VALEO197485 ZF DF6110_TRW1 ZFDF6110TRW1 ZIMMERMANN109901417 ZIMMERMANN470243720

OE Numbers — MERCEDES-BENZ 415 420 00

01

OE Numbers — MERCEDES-BENZ

4154200001 4154200701 4154210412 A4154200001 A4154200701 A4154210412

OE Numbers — MERCEDES-BENZ 415 421 04

12

OE Numbers — NISSAN

40206-00Q2G 40206-00Q2L

OE Numbers — RENAULT 40 20 642

30R

OE Numbers — RENAULT

402064230R 402064442R 7701209839 8201464604 8660005363 8671016877

OE Numbers — RENAULT 40 20 644

42R

OE Numbers — RENAULT 77 01 209

839

OE Numbers — RENAULT 82 01 464

604

OE Numbers — RENAULT 86 60 005

363

OE Numbers — RENAULT 86 71 016

877
MakeModelType / Engine YearsCCkWHP
MERCEDES-BENZ CITAN Box Body/MPV (W415) 108 CDI (415.601, 415.603) 2012 – 2021 1461 55 75
MERCEDES-BENZ CITAN Box Body/MPV (W415) 109 CDI (415.601, 415.603, 415.605) 2012 – 2021 1461 66 90
MERCEDES-BENZ CITAN Box Body/MPV (W415) 112 (415.603) 2012 – 2021 1197 84 114
MERCEDES-BENZ CITAN Box Body/MPV (W415) 111 CDI (415.603, 415.605) 2012 – 2021 1461 81 110
MERCEDES-BENZ CITAN Box Body/MPV (W415) 108 CDI (415.603) 2012 – 2021 1461 59 80
MERCEDES-BENZ CITAN Box Body/MPV (W415) 109 CDI (415.603, 415.605) 2012 – 2021 1461 70 95
MERCEDES-BENZ CITAN Box Body/MPV (W415) 111 CDI (415.603, 415.605) 2012 – 2021 1461 85 116
MERCEDES-BENZ CITAN Mixto (Double Cabin) (W415) 109 CDI (415.603, 415.605) 2012 – 2021 1461 66 90
MERCEDES-BENZ CITAN Mixto (Double Cabin) (W415) 111 CDI (415.603, 415.605) 2012 – 2021 1461 81 110
MERCEDES-BENZ CITAN MPV (W415) 108 CDI (415.703) 2012 – 2021 1461 55 75
MERCEDES-BENZ CITAN MPV (W415) 109 CDI (415.703) 2012 – 2021 1461 66 90
MERCEDES-BENZ CITAN MPV (W415) 111 CDI (415.703, 415.705) 2012 – 2021 1461 81 110
MERCEDES-BENZ CITAN MPV (W415) 112 (415.703) 2012 – 2021 1197 84 114
MERCEDES-BENZ CITAN MPV (W415) 108 CDI (415.703) 2012 – 2021 1461 59 80
MERCEDES-BENZ CITAN MPV (W415) 109 CDI (415.703) 2012 – 2021 1461 70 95
MERCEDES-BENZ CITAN MPV (W415) 111 CDI (415.703) 2012 – 2021 1461 85 116
