Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Brake Disc Thickness (mm) | 24 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 67 |
| Colour black | |
| Height (mm) | 66.2 |
| Minimum thickness (mm) | 22.4 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 307 |
| Surface Painted | |
| Test Mark E1 90R-02 C0176/0615 | |
| Thread Size 16,6 | |
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 24, Brake Disc Type Vented, Centering Diameter [mm] 67, Colour black, Height [mm] 66,2, Minimum thickness [mm] 22,4, Number of Holes 5, Outer Diameter [mm] 307, Surface Painted, Test Mark E1 90R-02 C0176/0615, Thread Size 16,6
Fits: BMW
Fits: BMW
Supplier Cross-References
Interchangeable Part Numbers
OE Numbers — BMW (BRILLIANCE) 34 10 6 879
OE Numbers — BMW (BRILLIANCE)
OE Numbers — BMW 34 10 6 877
OE Numbers — BMW
OE Numbers — BMW 34 10 6 880
OE Numbers — BMW 34 10 6 890
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| BMW | 3 (G20, G80, G28) | 316 d Mild-Hybrid | 2018 – present | 1995 | 85 | 116 |
| BMW | 3 (G20, G80, G28) | M 340 i | 2018 – present | 2998 | 285 | 387 |
| BMW | 3 (G20, G80, G28) | M 340 i xDrive | 2018 – present | 2998 | 285 | 387 |
| BMW | 3 (G20, G80, G28) | 320 d Mild-Hybrid | 2018 – present | 1995 | 120 | 163 |
| BMW | 3 (G20, G80, G28) | 320 d Mild-Hybrid xDrive | 2018 – present | 1995 | 120 | 163 |
| BMW | 3 (G20, G80, G28) | 320 d Mild-Hybrid xDrive | 2018 – present | 1995 | 140 | 190 |
| BMW | 3 (G20, G80, G28) | 320 Ld | 2018 – present | 1995 | 140 | 190 |
| BMW | 3 (G20, G80, G28) | M3 Competition xDrive | 2018 – present | 2993 | 375 | 510 |
| BMW | 3 (G20, G80, G28) | 330 Li | 2018 – present | 1998 | 190 | 255 |
| BMW | 3 (G20, G80, G28) | 318 i | 2018 – present | 1998 | 115 | 156 |
| BMW | 3 (G20, G80, G28) | 330 e Plug-in-Hybrid xDrive | 2018 – present | 1998 | 215 | 292 |
| BMW | 3 (G20, G80, G28) | M 340 i Mild-Hybrid xDrive | 2018 – present | 2998 | 275 | 374 |
| BMW | 3 (G20, G80, G28) | M340 d Mild-Hybrid xDrive | 2018 – present | 2993 | 250 | 340 |
| BMW | 3 (G20, G80, G28) | 320 d Mild-Hybrid | 2018 – present | 1995 | 140 | 190 |
| BMW | 3 (G20, G80, G28) | 316 d | 2018 – present | 1995 | 85 | 116 |
| BMW | 3 (G20, G80, G28) | 330 d Mild-Hybrid xDrive | 2018 – present | 2993 | 210 | 286 |
| BMW | 3 (G20, G80, G28) | 316 d | 2018 – present | 1995 | 90 | 122 |
| BMW | 3 (G20, G80, G28) | 330 e Plug-in-Hybrid | 2018 – present | 1998 | 215 | 292 |
| BMW | 3 (G20, G80, G28) | 330 d Mild-Hybrid | 2018 – present | 2993 | 210 | 286 |
| BMW | 3 (G20, G80, G28) | 316 d Mild-Hybrid | 2018 – present | 1995 | 90 | 122 |
| BMW | 3 (G20, G80, G28) | 318 d Mild-Hybrid | 2018 – present | 1995 | 100 | 136 |
| BMW | 3 (G20, G80, G28) | 318 d Mild-Hybrid | 2018 – present | 1995 | 110 | 150 |
| BMW | 3 (G20, G80, G28) | M3 Competition | 2018 – present | 2993 | 375 | 510 |
| BMW | 3 (G20, G80, G28) | M3 | 2018 – present | 2993 | 353 | 480 |
| BMW | 3 (G20, G80, G28) | 320 e Plug-in-Hybrid | 2018 – present | 1998 | 150 | 204 |
| BMW | 3 (G20, G80, G28) | 330 i xDrive | 2018 – present | 1998 | 180 | 245 |
| BMW | 3 (G20, G80, G28) | 320 d | 2018 – present | 1995 | 140 | 190 |
| BMW | 3 (G20, G80, G28) | 320 d xDrive | 2018 – present | 1995 | 140 | 190 |
| BMW | 3 (G20, G80, G28) | 320 d | 2018 – present | 1995 | 120 | 163 |
| BMW | 3 (G20, G80, G28) | 320 d xDrive | 2018 – present | 1995 | 120 | 163 |
| BMW | 3 (G20, G80, G28) | M 340 i xDrive | 2018 – present | 2998 | 275 | 374 |
| BMW | 3 (G20, G80, G28) | 320 i | 2018 – present | 1998 | 135 | 184 |
| BMW | 3 (G20, G80, G28) | 318 d | 2018 – present | 1995 | 110 | 150 |
| BMW | 3 (G20, G80, G28) | 318 d | 2018 – present | 1995 | 100 | 136 |
| BMW | 3 (G20, G80, G28) | 330 d | 2018 – present | 2993 | 195 | 265 |
| BMW | 3 (G20, G80, G28) | 320 i 1.6 | 2018 – present | 1597 | 125 | 170 |
| BMW | 3 (G20, G80, G28) | 320 i xDrive | 2018 – present | 1998 | 135 | 184 |
| BMW | 3 (G20, G80, G28) | 330 i xDrive | 2018 – present | 1998 | 190 | 258 |
| BMW | 3 (G20, G80, G28) | 330 d xDrive | 2018 – present | 2993 | 195 | 265 |
| BMW | 3 (G20, G80, G28) | 330 i | 2018 – present | 1998 | 190 | 258 |
| BMW | 3 (G20, G80, G28) | 330 i | 2018 – present | 1998 | 180 | 245 |
| BMW | 3 (G20, G80, G28) | 2.0 320i ActiveFlex | 2018 – present | 1998 | 135 | 184 |
| BMW | 3 (G20, G80, G28) | 330 i Mild-Hybrid | 2018 – present | 1998 | 190 | 258 |
| BMW | 3 (G20, G80, G28) | 330 i Mild-Hybrid xDrive | 2018 – present | 1998 | 190 | 258 |
| BMW | 3 (G20, G80, G28) | M3 CS xDrive | 2018 – present | 2993 | 405 | 551 |
| BMW | 3 (G20, G80, G28) | M340 i Mild-Hybrid xDrive | 2018 – present | 2998 | 288 | 392 |
| BMW | 3 (G20, G80, G28) | M3 Competition xDrive | 2018 – present | 2993 | 390 | 530 |
| BMW | 3 Touring (G21, G81) | 330 d Mild-Hybrid | 2019 – present | 2993 | 210 | 286 |
| BMW | 3 Touring (G21, G81) | M3 Competition xDrive | 2019 – present | 2993 | 375 | 510 |
| BMW | 3 Touring (G21, G81) | 330 i xDrive | 2019 – present | 1998 | 180 | 245 |
| BMW | 3 Touring (G21, G81) | M 340 i xDrive | 2019 – present | 2998 | 288 | 392 |
| BMW | 3 Touring (G21, G81) | M3 Competition xDrive | 2019 – present | 2993 | 390 | 530 |
| BMW | 3 Touring (G21, G81) | 330 i | 2019 – present | 1998 | 180 | 245 |
| BMW | 3 Touring (G21, G81) | M3 CS xDrive | 2019 – present | 2993 | 405 | 551 |
| BMW | 3 Touring (G21, G81) | 330 d Mild-Hybrid xDrive | 2019 – present | 2993 | 210 | 286 |
| BMW | 3 Touring (G21, G81) | M 340 i xDrive | 2019 – present | 2998 | 285 | 387 |
| BMW | 3 Touring (G21, G81) | 316 d | 2019 – present | 1995 | 90 | 122 |
| BMW | 3 Touring (G21, G81) | 316 d | 2019 – present | 1995 | 85 | 116 |
| BMW | 3 Touring (G21, G81) | 316 d Mild-Hybrid | 2019 – present | 1995 | 85 | 116 |
| BMW | 3 Touring (G21, G81) | M 340 i Mild-Hybrid xDrive | 2019 – present | 2998 | 275 | 374 |
| BMW | 3 Touring (G21, G81) | 320 e Plug-in-Hybrid xDrive | 2019 – present | 1998 | 150 | 204 |
| BMW | 3 Touring (G21, G81) | 320 d | 2019 – present | 1995 | 140 | 190 |
| BMW | 3 Touring (G21, G81) | 320 e Plug-in-Hybrid | 2019 – present | 1998 | 150 | 204 |
| BMW | 3 Touring (G21, G81) | 320 d Mild-Hybrid | 2019 – present | 1995 | 140 | 190 |
| BMW | 3 Touring (G21, G81) | 320 d Mild-Hybrid | 2019 – present | 1995 | 120 | 163 |
| BMW | 3 Touring (G21, G81) | 330 d | 2019 – present | 2993 | 195 | 265 |
| BMW | 3 Touring (G21, G81) | 330 e Plug-in-Hybrid | 2019 – present | 1998 | 215 | 292 |
| BMW | 3 Touring (G21, G81) | 330 d xDrive | 2019 – present | 2993 | 195 | 265 |
| BMW | 3 Touring (G21, G81) | 320 d xDrive | 2019 – present | 1995 | 140 | 190 |
| BMW | 3 Touring (G21, G81) | 320 d xDrive | 2019 – present | 1995 | 120 | 163 |
| BMW | 3 Touring (G21, G81) | 320 d Mild-Hybrid xDrive | 2019 – present | 1995 | 120 | 163 |
| BMW | 3 Touring (G21, G81) | 320 d | 2019 – present | 1995 | 120 | 163 |
| BMW | 3 Touring (G21, G81) | 318 d | 2019 – present | 1995 | 110 | 150 |
| BMW | 3 Touring (G21, G81) | 318 d | 2019 – present | 1995 | 100 | 136 |
| BMW | 3 Touring (G21, G81) | M 340 i xDrive | 2019 – present | 2998 | 275 | 374 |
| BMW | 3 Touring (G21, G81) | 330 i xDrive | 2019 – present | 1998 | 190 | 258 |
| BMW | 3 Touring (G21, G81) | 330 i | 2019 – present | 1998 | 190 | 258 |
| BMW | 3 Touring (G21, G81) | 320 i | 2019 – present | 1998 | 135 | 184 |
| BMW | 3 Touring (G21, G81) | 318 i | 2019 – present | 1998 | 115 | 156 |
| BMW | 3 Touring (G21, G81) | 318 d Mild-Hybrid | 2019 – present | 1995 | 110 | 150 |
| BMW | 3 Touring (G21, G81) | 318 d Mild-Hybrid | 2019 – present | 1995 | 100 | 136 |
| BMW | 3 Touring (G21, G81) | 316 d Mild-Hybrid | 2019 – present | 1995 | 90 | 122 |
| BMW | 3 Touring (G21, G81) | M 340 d Mild-Hybrid xDrive | 2019 – present | 2993 | 250 | 340 |
| BMW | 3 Touring (G21, G81) | 330 e Plug-in-Hybrid xDrive | 2019 – present | 1998 | 215 | 292 |
| BMW | 3 Touring (G21, G81) | 320 d Mild-Hybrid xDrive | 2019 – present | 1995 | 140 | 190 |
| BMW | 3 Touring Van (G21) | 320 i | 2019 – present | 1998 | 135 | 184 |
| BMW | 3 Touring Van (G21) | 330 i | 2019 – present | 1998 | 190 | 258 |
| BMW | 3 Touring Van (G21) | M 340 i xDrive | 2019 – present | 2998 | 275 | 374 |
| BMW | 3 Touring Van (G21) | 320 d | 2019 – present | 1995 | 140 | 190 |
| BMW | 3 Touring Van (G21) | 320 d Mild-Hybrid | 2019 – present | 1995 | 140 | 190 |
| BMW | 3 Touring Van (G21) | 318 d | 2019 – present | 1995 | 110 | 150 |
| BMW | 3 Touring Van (G21) | 320 d xDrive | 2019 – present | 1995 | 140 | 190 |
| BMW | 3 Touring Van (G21) | 320 d Mild-Hybrid xDrive | 2019 – present | 1995 | 140 | 190 |
| BMW | 3 Touring Van (G21) | 330 d | 2019 – present | 2993 | 195 | 265 |
| BMW | 3 Touring Van (G21) | 330 d xDrive | 2019 – present | 2993 | 195 | 265 |
