Specifications
| Bolt Hole Circle Ø (mm) | 114.3 |
| Brake Disc Thickness (mm) | 23 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 70.1 |
| Height (mm) | 52.1 |
| Minimum thickness (mm) | 21 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 282 |
| Thread Size 12.5 | |
Bolt Hole Circle Ø [mm] 114,3, Brake Disc Thickness [mm] 23, Brake Disc Type Vented, Centering Diameter [mm] 70,1, Height [mm] 52,1, Minimum thickness [mm] 21, Number of Holes 5, Outer Diameter [mm] 282, Thread Size 12.5
