Specifications
| Bolt Hole Circle Ø (mm) | 124 |
| Brake Disc Thickness (mm) | 26 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 100 |
| Height (mm) | 39.2 |
| Minimum thickness (mm) | 24 |
| Number of Holes 6 | |
| Outer Diameter (mm) | 260 |
| Thread Size M10 x 1.25 | |
Bolt Hole Circle Ø [mm] 124, Brake Disc Thickness [mm] 26, Brake Disc Type Vented, Centering Diameter [mm] 100, Height [mm] 39,2, Minimum thickness [mm] 24, Number of Holes 6, Outer Diameter [mm] 260, Thread Size M10 x 1.25
