Specifications
| Bolt Hole Circle Ø (mm) | 139.7 |
| Brake Disc Thickness (mm) | 28 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 94 |
| Height (mm) | 46.3 |
| Minimum thickness (mm) | 26.4 |
| Number of Holes 6 | |
| Outer Diameter (mm) | 294 |
| Thread Size 12.6 | |
Bolt Hole Circle Ø [mm] 139,7, Brake Disc Thickness [mm] 28, Brake Disc Type Vented, Centering Diameter [mm] 94, Height [mm] 46,3, Minimum thickness [mm] 26,4, Number of Holes 6, Outer Diameter [mm] 294, Thread Size 12.6
