Specifications
| Bolt Hole Circle Ø (mm) | 100 |
| Brake Disc Thickness (mm) | 22 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 61 |
| Fitting Position Front Axle | |
| Height (mm) | 45.2 |
| Minimum thickness (mm) | 20 |
| Number of Holes 4 | |
| Outer Diameter (mm) | 238 |
| Thread Size 12.7 | |
Bolt Hole Circle Ø [mm] 100, Brake Disc Thickness [mm] 22, Brake Disc Type Vented, Centering Diameter [mm] 61, Fitting Position Front Axle, Height [mm] 45,2, Minimum thickness [mm] 20, Number of Holes 4, Outer Diameter [mm] 238, Thread Size 12.7
