Specifications
| Bolt Hole Circle Ø (mm) | 114.3 |
| Brake Disc Thickness (mm) | 26 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 92 |
| Height (mm) | 40 |
| Minimum thickness (mm) | 24 |
| Number of Holes 6 | |
| Outer Diameter (mm) | 263 |
| Thread Size 10.6 | |
Bolt Hole Circle Ø [mm] 114,3, Brake Disc Thickness [mm] 26, Brake Disc Type Vented, Centering Diameter [mm] 92, Height [mm] 40, Minimum thickness [mm] 24, Number of Holes 6, Outer Diameter [mm] 263, Thread Size 10.6
