Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Brake Disc Thickness (mm) | 30 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 67 |
| Height (mm) | 51.1 |
| Minimum thickness (mm) | 28 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 320 |
| Thread Size 15.3 | |
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 30, Brake Disc Type Vented, Centering Diameter [mm] 67, Height [mm] 51,1, Minimum thickness [mm] 28, Number of Holes 5, Outer Diameter [mm] 320, Thread Size 15.3
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | A-CLASS (W176) | A 200 CDI / d 4-matic (176.002) | 2012 – 2018 | 2143 | 100 | 136 |
| MERCEDES-BENZ | A-CLASS (W176) | A 200 Flex (176.043) | 2012 – 2018 | 1595 | 115 | 156 |
| MERCEDES-BENZ | A-CLASS (W176) | A 180 CDI (176.007) | 2012 – 2018 | 2143 | 80 | 109 |
| MERCEDES-BENZ | A-CLASS (W176) | A 220 d 4-matic (176.005) | 2012 – 2018 | 2143 | 130 | 177 |
| MERCEDES-BENZ | A-CLASS (W176) | A 220 d (176.003) | 2012 – 2018 | 2143 | 130 | 177 |
| MERCEDES-BENZ | A-CLASS (W176) | AMG A 45 4-matic (176.052) | 2012 – 2018 | 1991 | 280 | 381 |
| MERCEDES-BENZ | A-CLASS (W176) | A 250 4-matic (176.051) | 2012 – 2018 | 1991 | 160 | 218 |
| MERCEDES-BENZ | A-CLASS (W176) | A 250 (176.050) | 2012 – 2018 | 1991 | 160 | 218 |
| MERCEDES-BENZ | A-CLASS (W176) | A 160 (176.041) | 2012 – 2018 | 1595 | 75 | 102 |
| MERCEDES-BENZ | A-CLASS (W176) | A 220 4-matic (176.047) | 2012 – 2018 | 1991 | 135 | 184 |
| MERCEDES-BENZ | A-CLASS (W176) | A 220 CDI (176.003) | 2012 – 2018 | 2143 | 120 | 163 |
| MERCEDES-BENZ | A-CLASS (W176) | A 220 CDI 4-matic (176.005) | 2012 – 2018 | 2143 | 125 | 170 |
| MERCEDES-BENZ | A-CLASS (W176) | A 180 (176.042) | 2012 – 2018 | 1595 | 90 | 122 |
| MERCEDES-BENZ | A-CLASS (W176) | A 200 CDI / d (176.008) | 2012 – 2018 | 2143 | 100 | 136 |
| MERCEDES-BENZ | A-CLASS (W176) | A 250 4-matic (176.046) | 2012 – 2018 | 1991 | 155 | 211 |
| MERCEDES-BENZ | A-CLASS (W176) | A 160 CDI / d (176.011) | 2012 – 2018 | 1461 | 66 | 90 |
| MERCEDES-BENZ | A-CLASS (W176) | A 45 AMG 4-matic (176.052) | 2012 – 2018 | 1991 | 265 | 360 |
| MERCEDES-BENZ | A-CLASS (W176) | A 220 CDI (176.003) | 2012 – 2018 | 2143 | 125 | 170 |
| MERCEDES-BENZ | A-CLASS (W176) | A 200 CDI (176.001) | 2012 – 2018 | 1796 | 100 | 136 |
| MERCEDES-BENZ | A-CLASS (W176) | A 180 CDI (176.000) | 2012 – 2018 | 1796 | 80 | 109 |
| MERCEDES-BENZ | A-CLASS (W176) | A 180 CDI / d (176.012) | 2012 – 2018 | 1461 | 80 | 109 |
| MERCEDES-BENZ | A-CLASS (W176) | A 250 (176.044) | 2012 – 2018 | 1991 | 155 | 211 |
| MERCEDES-BENZ | A-CLASS (W176) | A 200 (176.043) | 2012 – 2018 | 1595 | 115 | 156 |
