Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Brake Disc Thickness (mm) | 34 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 68 |
| Height (mm) | 57.4 |
| Minimum thickness (mm) | 32 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 349 |
| Thread Size 15.2 | |
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 34, Brake Disc Type Vented, Centering Diameter [mm] 68, Height [mm] 57,4, Minimum thickness [mm] 32, Number of Holes 5, Outer Diameter [mm] 349, Thread Size 15.2
Fits: AUDI, AUDI (FAW), VW
Fits: AUDI, AUDI (FAW), VW
Interchangeable Part Numbers
OE Numbers — AUDI 4M0 615 301
OE Numbers — AUDI
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 165 | 224 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 180 | 245 |
| AUDI | Q7 (4LB) | 3.0 TFSI quattro | 2006 – 2016 | 2995 | 206 | 280 |
| AUDI | Q7 (4LB) | 4.2 FSI quattro | 2006 – 2016 | 4163 | 257 | 350 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 171 | 233 |
| AUDI | Q7 (4LB) | 3.6 FSI quattro | 2006 – 2016 | 3597 | 206 | 280 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 155 | 211 |
| AUDI | Q7 (4LB) | 4.2 TDI quattro | 2006 – 2016 | 4134 | 240 | 326 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 176 | 240 |
| AUDI | Q7 (4LB) | 6.0 TDI quattro | 2006 – 2016 | 5934 | 368 | 500 |
| AUDI | Q7 (4LB) | 4.2 TDI quattro | 2006 – 2016 | 4134 | 250 | 340 |
| AUDI | Q7 (4LB) | 3.0 TFSI quattro | 2006 – 2016 | 2995 | 200 | 272 |
| AUDI | Q7 (4LB) | 3.0 TFSI quattro | 2006 – 2016 | 2995 | 245 | 333 |
| AUDI | Q7 (4LB) | 3.0 TDI quattro | 2006 – 2016 | 2967 | 150 | 204 |
