Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Brake Disc Thickness (mm) | 36 |
| Brake Disc Type Vented | |
| Centering Diameter (mm) | 68 |
| Height (mm) | 58.1 |
| Minimum thickness (mm) | 34 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 374 |
| Thread Size 15.5 | |
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 36, Brake Disc Type Vented, Centering Diameter [mm] 68, Height [mm] 58,1, Minimum thickness [mm] 34, Number of Holes 5, Outer Diameter [mm] 374, Thread Size 15.5
Fits: AUDI, AUDI (FAW), AUDI (SAIC), VW
Fits: AUDI, AUDI (FAW), AUDI (SAIC), VW
OE Numbers — AUDI
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| AUDI | Q7 (4MB, 4MG, 4MQ) | 45 TFSI quattro | 2015 – present | 1984 | 180 | 245 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 60 TFSI e quattro | 2015 – present | 2995 | 360 | 489 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 55 TFSI e quattro | 2015 – present | 2995 | 290 | 394 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 55 e-tron quattro | 2015 – present | 1984 | 270 | 367 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 45 e-tron quattro | 2015 – present | 1984 | 270 | 367 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 45 TFSI quattro | 2015 – present | 1984 | 185 | 252 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 40 TFSI quattro | 2015 – present | 1984 | 185 | 252 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 3.0 55 TFSI quattro | 2015 – present | 2995 | 245 | 333 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 3.0 45 TFSI quattro | 2015 – present | 2995 | 245 | 333 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 60 TFSI e quattro | 2015 – present | 2995 | 340 | 462 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 45 TFSI Mild Hybrid quattro | 2015 – present | 1984 | 195 | 265 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 45 TFSI quattro | 2015 – present | 1984 | 195 | 265 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | SQ7 quattro | 2015 – present | 3956 | 310 | 421 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 45 TDI quattro | 2015 – present | 2967 | 183 | 249 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 55 TFSI quattro | 2015 – present | 2995 | 250 | 340 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | SQ7 quattro | 2015 – present | 3996 | 373 | 507 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 3.0 TFSI quattro | 2015 – present | 2995 | 245 | 333 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 60 TFSI e quattro | 2015 – present | 2995 | 335 | 455 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 55 TFSI e quattro | 2015 – present | 2995 | 280 | 381 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 55 TFSI Mild Hybrid quattro | 2015 – present | 2995 | 250 | 340 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 45 TDI Mild Hybrid quattro | 2015 – present | 2967 | 170 | 231 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 50 TDI Mild Hybrid quattro | 2015 – present | 2967 | 210 | 286 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 2.0 TFSI e-tron quattro | 2015 – present | 1984 | 270 | 367 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | SQ7 TDI quattro | 2015 – present | 3956 | 320 | 435 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 3.0 TDI quattro | 2015 – present | 2967 | 190 | 258 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 3.0 TDI e-tron quattro | 2015 – present | 2967 | 275 | 374 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 3.0 TDI quattro | 2015 – present | 2967 | 155 | 211 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 2.0 TFSI quattro | 2015 – present | 1984 | 185 | 252 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 3.0 TDI quattro | 2015 – present | 2967 | 160 | 218 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 3.0 TDI quattro | 2015 – present | 2967 | 183 | 249 |
| AUDI | Q7 (4MB, 4MG, 4MQ) | 3.0 TDI quattro | 2015 – present | 2967 | 200 | 272 |
