Specifications
| Bolt Hole Circle Ø (mm) | 112 |
| Brake Disc Thickness (mm) | 11 |
| Brake Disc Type solid | |
| Centering Diameter (mm) | 67 |
| Height (mm) | 42.5 |
| Minimum thickness (mm) | 9.3 |
| Number of Holes 5 | |
| Outer Diameter (mm) | 276 |
| Thread Size 15.2 | |
Bolt Hole Circle Ø [mm] 112, Brake Disc Thickness [mm] 11, Brake Disc Type solid, Centering Diameter [mm] 67, Height [mm] 42,5, Minimum thickness [mm] 9,3, Number of Holes 5, Outer Diameter [mm] 276, Thread Size 15.2
Fits: MERCEDES-BENZ, MERCEDES-BENZ (BBDC)
Fits: MERCEDES-BENZ, MERCEDES-BENZ (BBDC)
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 160 d (247.002) | 2018 – present | 1461 | 70 | 95 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 250 Mid Hybrid 4-matic (247.047) | 2018 – present | 1991 | 165 | 224 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 220 Mild-Hybrid 4-matic (247.045) | 2018 – present | 1991 | 140 | 190 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 200 Mild Hybrid (247.087) | 2018 – present | 1332 | 120 | 163 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 180 Mild Hybrid (247.084) | 2018 – present | 1332 | 100 | 136 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 250 e (247.085) | 2018 – present | 1332 | 160 | 218 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 200 4-matic (247.088) | 2018 – present | 1332 | 120 | 163 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 180 d (247.010) | 2018 – present | 1950 | 85 | 116 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 250 e (247.086) | 2018 – present | 1332 | 160 | 218 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 220 d 4-matic (247.015) | 2018 – present | 1950 | 140 | 190 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 200 d 4-matic (247.013) | 2018 – present | 1950 | 110 | 150 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 200 d (247.012) | 2018 – present | 1950 | 110 | 150 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 200 (247.087) | 2018 – present | 1332 | 110 | 150 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 160 (247.082) | 2018 – present | 1332 | 80 | 109 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 220 (247.044) | 2018 – present | 1991 | 140 | 190 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 250 4-matic (247.047) | 2018 – present | 1991 | 165 | 224 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 250 (247.046) | 2018 – present | 1991 | 165 | 224 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 220 4-matic (247.045) | 2018 – present | 1991 | 140 | 190 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 180 d (247.003) | 2018 – present | 1461 | 85 | 116 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 200 (247.087) | 2018 – present | 1332 | 120 | 163 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 180 (247.084) | 2018 – present | 1332 | 100 | 136 |
| MERCEDES-BENZ | B-CLASS Sports Tourer (W247) | B 220 d (247.014) | 2018 – present | 1950 | 140 | 190 |
