Specifications
| Bore Diameter 2 (mm) | 13 |
| Bore Diameter (mm) | 13 |
| Clamp 30 | |
| Clamp 50 | |
| Flange Diameter (mm) | 90 |
| Length (mm) | 294 |
| Mounting Angle (degrees) | 65 |
| Mounting bore angle measurement (degree) | 65 |
| Number of mounting bores 2 | |
| Number of Teeth 11 | |
| Number of threaded holes 0 | |
| Pinion Rest Position (mm) | 15.8 |
| Position/Degree rechts | |
| Rated Power (kW) | 2.7 |
| Rotation Direction Clockwise rotation | |
| Starter Type Floating pinion | |
Bore Diameter 2 [mm] 13, Bore Diameter [mm] 13, Clamp 30, Clamp 50, Flange Diameter [mm] 90, Length [mm] 294, Mounting Angle [degrees] 65, Mounting bore angle measurement [degree] 65, Number of mounting bores 2, Number of Teeth 11, Number of threaded holes 0, Pinion Rest Position [mm] 15,8, Position/Degree rechts, Rated Power [kW] 2,7, Rotation Direction Clockwise rotation, Starter Type Floating pinion, Voltage [V] 12
