Specifications
| Colour Coding blue | |
| Colour Coding green | |
| Fitting Position Rear Axle | |
| Length (mm) | 353 |
| Multiple 1 | |
| Multiple 3 | |
| Outer Diameter (mm) | 103 |
| Spring Design Coil spring with constant wire diameter | |
| Thickness (mm) | 15.25 |
| Weight (kg) | 3.33 |
Colour Coding blue, Colour Coding green, Fitting Position Rear Axle, Length [mm] 353, Multiple 1, Multiple 3, Outer Diameter [mm] 103, Spring Design Coil spring with constant wire diameter, Thickness [mm] 15,25, Weight [kg] 3,33
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ 211 324 08
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | E-CLASS (W211) | E 220 CDI (211.006) | 2002 – 2009 | 2148 | 100 | 136 |
| MERCEDES-BENZ | E-CLASS (W211) | E 420 CDI (211.029) | 2002 – 2009 | 3996 | 231 | 314 |
| MERCEDES-BENZ | E-CLASS (W211) | E 280 4-matic (211.092) | 2002 – 2009 | 2996 | 170 | 231 |
| MERCEDES-BENZ | E-CLASS (W211) | E 350 4-matic (211.087) | 2002 – 2009 | 3498 | 200 | 272 |
| MERCEDES-BENZ | E-CLASS (W211) | E 320 CDI 4-matic (211.089) | 2002 – 2009 | 2987 | 165 | 224 |
| MERCEDES-BENZ | E-CLASS (W211) | E 200 CDI (211.007) | 2002 – 2009 | 2148 | 100 | 136 |
| MERCEDES-BENZ | E-CLASS (W211) | E 220 CDI (211.008) | 2002 – 2009 | 2148 | 125 | 170 |
| MERCEDES-BENZ | E-CLASS (W211) | E 200 Kompressor (211.041) | 2002 – 2009 | 1796 | 135 | 184 |
| MERCEDES-BENZ | E-CLASS (W211) | E 500 4-matic (211.090) | 2002 – 2009 | 5461 | 285 | 388 |
| MERCEDES-BENZ | E-CLASS (W211) | E 500 (211.072) | 2002 – 2009 | 5461 | 285 | 388 |
| MERCEDES-BENZ | E-CLASS (W211) | E 63 AMG (211.077) | 2002 – 2009 | 6208 | 378 | 514 |
| MERCEDES-BENZ | E-CLASS (W211) | E 280 CDI 4-matic (211.084) | 2002 – 2009 | 2987 | 140 | 190 |
| MERCEDES-BENZ | E-CLASS (W211) | E 350 CGI (211.057) | 2002 – 2009 | 3498 | 215 | 292 |
| MERCEDES-BENZ | E-CLASS (W211) | E 300 BlueTEC (211.024) | 2002 – 2009 | 2987 | 155 | 211 |
| MERCEDES-BENZ | E-CLASS (W211) | E 230 (211.052) | 2002 – 2009 | 2496 | 150 | 204 |
| MERCEDES-BENZ | E-CLASS (W211) | E 350 4-matic (211.087) | 2002 – 2009 | 3498 | 205 | 279 |
| MERCEDES-BENZ | E-CLASS (W211) | E 500 (211.070) | 2002 – 2009 | 4966 | 215 | 292 |
| MERCEDES-BENZ | E-CLASS (W211) | E320 CDI (211.022) | 2002 – 2009 | 2987 | 156 | 212 |
| MERCEDES-BENZ | E-CLASS (W211) | E 270 CDI (211.016) | 2002 – 2009 | 2685 | 120 | 163 |
| MERCEDES-BENZ | E-CLASS (W211) | E 320 BlueTEC (211.022) | 2002 – 2009 | 2987 | 156 | 212 |
| MERCEDES-BENZ | E-CLASS (W211) | E 63 AMG (211.077) | 2002 – 2009 | 6208 | 378 | 514 |
| MERCEDES-BENZ | E-CLASS (W211) | E 240 (211.061) | 2002 – 2009 | 2597 | 120 | 163 |
| MERCEDES-BENZ | E-CLASS (W211) | E 200 Kompressor (211.042) | 2002 – 2009 | 1796 | 120 | 163 |
| MERCEDES-BENZ | E-CLASS (W211) | E 320 (211.065) | 2002 – 2009 | 3199 | 165 | 224 |
| MERCEDES-BENZ | E-CLASS (W211) | E 500 (211.070) | 2002 – 2009 | 4966 | 225 | 306 |
| MERCEDES-BENZ | E-CLASS (W211) | E 240 (211.061) | 2002 – 2009 | 2597 | 130 | 177 |
| MERCEDES-BENZ | E-CLASS (W211) | E 220 CDI (211.006) | 2002 – 2009 | 2148 | 110 | 150 |
| MERCEDES-BENZ | E-CLASS (W211) | E 270 CDI (211.016) | 2002 – 2009 | 2685 | 130 | 177 |
| MERCEDES-BENZ | E-CLASS (W211) | E 240 4-matic (211.080) | 2002 – 2009 | 2597 | 130 | 177 |
| MERCEDES-BENZ | E-CLASS (W211) | E 320 4-matic (211.082) | 2002 – 2009 | 3199 | 165 | 224 |
| MERCEDES-BENZ | E-CLASS (W211) | E 200 CDI (211.004) | 2002 – 2009 | 2148 | 75 | 102 |
| MERCEDES-BENZ | E-CLASS (W211) | E 200 CDI (211.004) | 2002 – 2009 | 2148 | 90 | 122 |
| MERCEDES-BENZ | E-CLASS (W211) | E 55 AMG Kompressor (211.076) | 2002 – 2009 | 5439 | 350 | 476 |
| MERCEDES-BENZ | E-CLASS (W211) | E 220 CDI | 2002 – 2009 | 2149 | 120 | 163 |
| MERCEDES-BENZ | E-CLASS (W211) | E 320 CDI (211.026) | 2002 – 2009 | 3222 | 150 | 204 |
| MERCEDES-BENZ | E-CLASS (W211) | E 400 CDI (211.028) | 2002 – 2009 | 3996 | 191 | 260 |
| MERCEDES-BENZ | E-CLASS (W211) | E 500 4-matic (211.083) | 2002 – 2009 | 4966 | 225 | 306 |
| MERCEDES-BENZ | E-CLASS (W211) | E 200 NGT (211.042) | 2002 – 2009 | 1796 | 120 | 163 |
| MERCEDES-BENZ | E-CLASS (W211) | E 280 CDI (211.023) | 2002 – 2009 | 3222 | 130 | 177 |
| MERCEDES-BENZ | E-CLASS (W211) | E 280 (211.054) | 2002 – 2009 | 2996 | 170 | 231 |
| MERCEDES-BENZ | E-CLASS (W211) | E 350 (211.056) | 2002 – 2009 | 3498 | 200 | 272 |
| MERCEDES-BENZ | E-CLASS (W211) | E 280 CDI (211.020) | 2002 – 2009 | 2987 | 140 | 190 |
| MERCEDES-BENZ | E-CLASS (W211) | E 320 CDI (211.022) | 2002 – 2009 | 2987 | 165 | 224 |
