Shock Absorber
Suspension/Damping

Shock Absorber

Part No. JGS9032T · SKU JGS9032T-TRW
Front Axle
Price on request
Currently out of stock

Get notified when this part is back in stock:

Genuine & OEM parts Nationwide delivery Easy returns

Specifications

Diameter 1 (mm)53
Fitting Position Front Axle, max. length (mm)526. min. length [mm] 380
Observe technical data
Piston Rod Diameter (mm)18
Quantity per axle 1
Shock Absorber Design Spring-bearing Damper
Shock Absorber Mounting Type Top pin
Shock Absorber Type Gas Pressure
Thread Size M12*1.5
Diameter 1 [mm] 53, Fitting Position Front Axle, max. length [mm] 526, min. length [mm] 380, Observe technical data , Piston Rod Diameter [mm] 18, Quantity per axle 1, Shock Absorber Design Spring-bearing Damper, Shock Absorber Mounting Type Top pin, Shock Absorber Type Gas Pressure, Thread Size M12*1.5
Fits: AUDI, AUDI (FAW)

OE Numbers — AUDI (FAW)

8K0413031BL
MakeModelType / Engine YearsCCkWHP
AUDI A5 (8T3) 3.0 TDI quattro 2007 – 2017 2967 160 218
AUDI A5 (8T3) 3.0 TDI quattro 2007 – 2017 2967 155 211
AUDI A5 (8T3) 2.0 TDI 2007 – 2017 1968 125 170
AUDI A5 (8T3) 2.0 TDI quattro 2007 – 2017 1968 125 170
AUDI A5 (8T3) 1.8 TFSI 2007 – 2017 1798 118 160
AUDI A5 (8T3) 2.0 TDI 2007 – 2017 1968 120 163
AUDI A5 (8T3) 2.0 TFSI 2007 – 2017 1984 165 224
AUDI A5 (8T3) 2.0 TFSI quattro 2007 – 2017 1984 165 224
AUDI A5 (8T3) 2.0 TDI 2007 – 2017 1968 140 190
AUDI A5 (8T3) 2.0 TDI quattro 2007 – 2017 1968 140 190
AUDI A5 (8T3) 2.0 TFSI quattro 2007 – 2017 1984 162 220
AUDI A5 (8T3) 1.8 TFSI 2007 – 2017 1798 130 177
AUDI A5 (8T3) 2.0 TDI 2007 – 2017 1968 130 177
AUDI A5 (8T3) 2.0 TFSI quattro 2007 – 2017 1984 169 230
AUDI A5 (8T3) 2.0 TFSI 2007 – 2017 1984 169 230
AUDI A5 (8T3) 2.0 TFSI Flexfuel quattro 2007 – 2017 1984 162 220
AUDI A5 (8T3) S5 quattro 2007 – 2017 2995 249 339
AUDI A5 (8T3) 2.0 TFSI Flexfuel quattro 2007 – 2017 1984 155 211
AUDI A5 (8T3) 1.8 35 TFSI 2007 – 2017 1798 130 177
AUDI A5 (8T3) 45 TFSI quattro 2007 – 2017 1984 169 230
AUDI A5 (8T3) 45 TFSI 2007 – 2017 1984 169 230
AUDI A5 (8T3) 45 TFSI 2007 – 2017 1984 165 224
AUDI A5 (8T3) 45 TFSI quattro 2007 – 2017 1984 165 224
AUDI A5 (8T3) 2.0 TFSI quattro 2007 – 2017 1984 155 211
AUDI A5 (8T3) RS5 quattro 2007 – 2017 4163 331 450
AUDI A5 (8T3) 3.0 TDI 2007 – 2017 2967 150 204
AUDI A5 (8T3) 3.0 TDI quattro 2007 – 2017 2967 180 245
AUDI A5 (8T3) S5 quattro 2007 – 2017 2995 245 333
AUDI A5 (8T3) 1.8 TFSI 2007 – 2017 1798 125 170
AUDI A5 (8T3) 3.2 FSI 2007 – 2017 3197 195 265
AUDI A5 (8T3) S5 quattro 2007 – 2017 4163 260 354
AUDI A5 (8T3) 2.7 TDI 2007 – 2017 2698 140 190
AUDI A5 (8T3) 3.0 TDI quattro 2007 – 2017 2967 176 240
AUDI A5 (8T3) 2.0 TDI quattro 2007 – 2017 1968 130 177
AUDI A5 (8T3) 3.0 TFSI quattro 2007 – 2017 2995 200 272
AUDI A5 (8T3) 2.7 TDI 2007 – 2017 2698 120 163
AUDI A5 (8T3) 2.0 TFSI 2007 – 2017 1984 155 211
AUDI A5 (8T3) 2.0 TFSI 2007 – 2017 1984 132 180
AUDI A5 (8T3) 3.2 FSI quattro 2007 – 2017 3197 195 265
AUDI A5 Sportback (8TA) 3.0 TDI quattro 2007 – 2017 2967 160 218
AUDI A5 Sportback (8TA) 2.0 TFSI quattro 2007 – 2017 1984 155 211
AUDI A5 Sportback (8TA) 2.0 TDI quattro 2007 – 2017 1968 130 177
AUDI A5 Sportback (8TA) 3.0 TFSI quattro 2007 – 2017 2995 200 272
AUDI A5 Sportback (8TA) 2.0 TFSI 2007 – 2017 1984 169 230
AUDI A5 Sportback (8TA) 2.0 TFSI quattro 2007 – 2017 1984 169 230
AUDI A5 Sportback (8TA) 2.0 TFSI 2007 – 2017 1984 132 180
AUDI A5 Sportback (8TA) 1.8 TFSI 2007 – 2017 1798 125 170
AUDI A5 Sportback (8TA) 3.0 TDI quattro 2007 – 2017 2967 180 245
AUDI A5 Sportback (8TA) 3.0 TDI 2007 – 2017 2967 150 204
AUDI A5 Sportback (8TA) 1.8 35 TFSI 2007 – 2017 1798 130 177
AUDI A5 Sportback (8TA) 2.0 TDI 2007 – 2017 1968 130 177
AUDI A5 Sportback (8TA) 45 TFSI 2007 – 2017 1984 169 230
AUDI A5 Sportback (8TA) 45 TFSI quattro 2007 – 2017 1984 169 230
AUDI A5 Sportback (8TA) 45 TFSI 2007 – 2017 1984 165 224
AUDI A5 Sportback (8TA) 45 TFSI quattro 2007 – 2017 1984 165 224
AUDI A5 Sportback (8TA) 2.0 TDI 2007 – 2017 1968 120 163
AUDI A5 Sportback (8TA) 2.0 TFSI 2007 – 2017 1984 155 211
AUDI A5 Sportback (8TA) S5 quattro 2007 – 2017 2995 245 333
AUDI A5 Sportback (8TA) 2.0 TDI 2007 – 2017 1968 100 136
AUDI A5 Sportback (8TA) 2.0 TDI 2007 – 2017 1968 105 143
AUDI A5 Sportback (8TA) 2.7 TDI 2007 – 2017 2698 120 163
AUDI A5 Sportback (8TA) 2.0 TDI quattro 2007 – 2017 1968 125 170
AUDI A5 Sportback (8TA) 2.0 TFSI 2007 – 2017 1984 165 224
AUDI A5 Sportback (8TA) 2.0 TFSI quattro 2007 – 2017 1984 165 224
AUDI A5 Sportback (8TA) 2.0 TDI 2007 – 2017 1968 110 150
AUDI A5 Sportback (8TA) 1.8 TFSI 2007 – 2017 1798 130 177
AUDI A5 Sportback (8TA) 2.0 TDI 2007 – 2017 1968 140 190
AUDI A5 Sportback (8TA) 2.0 TDI quattro 2007 – 2017 1968 140 190
AUDI A5 Sportback (8TA) 3.0 TDI quattro 2007 – 2017 2967 176 240
AUDI A5 Sportback (8TA) 2.7 TDI 2007 – 2017 2698 140 190
AUDI A5 Sportback (8TA) 2.0 TDI 2007 – 2017 1968 125 170
AUDI A5 Sportback (8TA) 1.8 TFSI 2007 – 2017 1798 106 144
AUDI A5 Sportback (8TA) 3.2 FSI quattro 2007 – 2017 3197 195 265
AUDI A5 Sportback (8TA) 1.8 TFSI 2007 – 2017 1798 118 160
