Suspension/Damping

Shock Absorber

Name: Shock Absorber
Brand: TRW
SKU: JGT1250S-TRW
Availability: OutOfStock

Part No. JGT1250S · SKU JGT1250S-TRW

Front Axle

Price on request

Currently out of stock

Get notified when this part is back in stock:

Genuine & OEM parts Nationwide delivery Easy returns

Specifications

Diameter (mm)	60.5
Fitting Position Front Axle
Length 1 (mm)	380
Length 2 (mm)	298
Shock Absorber Design Telescopic Shock Absorber
Shock Absorber Mounting Type Bottom eye
Shock Absorber Mounting Type Top pin
Shock Absorber System Twin-Tube
Shock Absorber Type Gas Pressure
Standpipe Diameter (mm)	15

Diameter [mm] 60,5, Fitting Position Front Axle, Length 1 [mm] 380, Length 2 [mm] 298, Shock Absorber Design Telescopic Shock Absorber, Shock Absorber Mounting Type Bottom eye, Shock Absorber Mounting Type Top pin, Shock Absorber System Twin-Tube, Shock Absorber Type Gas Pressure, Standpipe Diameter [mm] 15
Fits: MERCEDES-BENZ

Interchangeable Part Numbers

AL-KO207423 AL-KO207433 BILSTEIN19-124551 BILSTEIN19-132501 GABRIELG71184 KYB349055 KYB349056 Magnum TechnologyAGM045MT MEYLE026 625 0015 MONROED8018 MONROED8018S

OE Numbers — MERCEDES-BENZ

163 326 00 00 163 326 02 00 163 326 04 00 163 326 07 00 163 326 11 00 163 326 12 00 A1633260000 A1633260200 A1633260400 A1633260700 A1633261100 A1633261200

Make	Model	Type / Engine	Years	CC	kW	HP
MERCEDES-BENZ	M-CLASS (W163)	ML 320 (163.154)	1998 – 2005	3199	160	218
MERCEDES-BENZ	M-CLASS (W163)	ML 230 (163.136)	1998 – 2005	2295	110	150
MERCEDES-BENZ	M-CLASS (W163)	ML 430 (163.172)	1998 – 2005	4266	200	272
MERCEDES-BENZ	M-CLASS (W163)	ML 270 CDI (163.113)	1998 – 2005	2685	120	163
MERCEDES-BENZ	M-CLASS (W163)	ML 55 AMG (163.174)	1998 – 2005	5439	255	347
MERCEDES-BENZ	M-CLASS (W163)	ML 400 CDI (163.128)	1998 – 2005	3996	184	250
MERCEDES-BENZ	M-CLASS (W163)	ML 500 (163.175)	1998 – 2005	4966	215	292
MERCEDES-BENZ	M-CLASS (W163)	ML 350 (163.157)	1998 – 2005	3724	180	245
MERCEDES-BENZ	M-CLASS (W163)	ML 350	1998 – 2005	3724	173	235
