Specifications
| Adapter Shape round | |
| Backflow Connector Thread Size M16x1,5 | |
| Belt Pulley Ø (mm) | 131 |
| Distance from adapter to pump (mm) | 31 |
| Distance of mounting bores (mm) | 58 |
| Exchange Part | |
| Left-/right-hand drive vehicles for left-hand drive vehicles | |
| Left-/right-hand drive vehicles for left-hand/right-hand drive vehicles | |
| Left-/right-hand drive vehicles for right-hand drive vehicles | |
| Manufacturer Restriction ZF | |
| Mounting points diameter (mm) | 8 |
| Number of inlets/outlets 2 | |
| Number of ribs 6 | |
| Observe technical data | |
| Operating Mode Hydraulic | |
| Suction pipe connector diameter (mm) | 16 |
Adapter Shape round, Backflow Connector Thread Size M16x1,5, Belt Pulley Ø [mm] 131, Distance from adapter to pump [mm] 31, Distance of mounting bores [mm] 58, Exchange Part , Left-/right-hand drive vehicles for left-hand drive vehicles, Left-/right-hand drive vehicles for left-hand/right-hand drive vehicles, Left-/right-hand drive vehicles for right-hand drive vehicles, Manufacturer Restriction ZF, Mounting points diameter [mm] 8, Number of inlets/outlets 2, Number of ribs 6, Observe technical data , Operating Mode Hydraulic, Suction pipe connector diameter [mm] 16
