Specifications
| Alternative Repair Kit JRP109 | |
| Connector Length (mm) | 43 |
| Connector type verzahnt | |
| Distance of mounting bores (mm) | 235 |
| External Thread 1 (mm) | M14 x 1.5 |
| Input Shaft Diameter (mm) | 17.5 |
| Left-/right-hand drive vehicles for left-hand drive vehicles | |
| Manufacturer Restriction ZF | |
| Number of Teeth on input shaft 54 | |
| Observe technical data | |
| Operating Mode Hydraulic | |
| Outer Length (mm) | 102 |
| Overall Length (mm) | 980 |
| Support plate diameter (mm) | 17.5 |
Alternative Repair Kit JRP109, Connector Length [mm] 43, Connector type verzahnt, Distance of mounting bores [mm] 235, External Thread 1 [mm] M14 x 1,5, Input Shaft Diameter [mm] 17,5, Left-/right-hand drive vehicles for left-hand drive vehicles, Manufacturer Restriction ZF, Number of Teeth on input shaft 54, Observe technical data , Operating Mode Hydraulic, Outer Length [mm] 102, Overall Length [mm] 980, Support plate diameter [mm] 17,5
