Specifications
| Axle Joint Length (mm) | 278 |
| Axle Joint Thread Size M14 x 1.5 | |
| Axle Joint Thread Type Internal Thread | |
| Input shaft connector type untoothed | |
| Input Shaft Diameter (mm) | 18.5 |
| Input shaft height (mm) | 40.5 |
| Left-/right-hand drive vehicles for right-hand drive vehicles | |
| Manufacturer Restriction ZF | |
| Observe technical data | |
| Operating Mode Hydraulic | |
| Overall Length (mm) | 1160 |
| Pressure Line Connection Thread Size M14x1,5 | |
| Suction pipe connector diameter (mm) | 16 |
Axle Joint Length [mm] 278, Axle Joint Thread Size M14 x 1.5, Axle Joint Thread Type Internal Thread, Input shaft connector type untoothed, Input Shaft Diameter [mm] 18,5, Input shaft height [mm] 40,5, Left-/right-hand drive vehicles for right-hand drive vehicles, Manufacturer Restriction ZF, Observe technical data , Operating Mode Hydraulic, Overall Length [mm] 1160, Pressure Line Connection Thread Size M14x1,5, Suction pipe connector diameter [mm] 16
