Specifications
| Backflow Connector Thread Size M16x1 | |
| Connector Length (mm) | 35 |
| Connector type verzahnt | |
| Distance of mounting bores (mm) | 360 |
| External Thread 1 (mm) | M16 x 1.5 |
| Input Shaft Diameter (mm) | 17.6 |
| Left-/right-hand drive vehicles for left-hand drive vehicles | |
| Number of Teeth on input shaft 54 | |
| Observe technical data | |
| Operating Mode Hydraulic | |
| Outer Length (mm) | 86 |
| Overall Length (mm) | 1040 |
| Pressure Line Connection Thread Size M14x1 | |
| Vehicle Equipment for vehicles with power steering | |
| Vehicle Equipment for vehicles without servotronic steering | |
Backflow Connector Thread Size M16x1, Connector Length [mm] 35, Connector type verzahnt, Distance of mounting bores [mm] 360, External Thread 1 [mm] M16 x 1.5, Input Shaft Diameter [mm] 17,6, Left-/right-hand drive vehicles for left-hand drive vehicles, Number of Teeth on input shaft 54, Observe technical data , Operating Mode Hydraulic, Outer Length [mm] 86, Overall Length [mm] 1040, Pressure Line Connection Thread Size M14x1, Vehicle Equipment for vehicles with power steering, Vehicle Equipment for vehicles without servotronic steering
Fits: MERCEDES-BENZ
Fits: MERCEDES-BENZ
Interchangeable Part Numbers
OE Numbers — MERCEDES-BENZ
| Make | Model | Type / Engine | Years | CC | kW | HP |
|---|---|---|---|---|---|---|
| MERCEDES-BENZ | M-CLASS (W163) | ML 320 (163.154) | 1998 – 2005 | 3199 | 160 | 218 |
| MERCEDES-BENZ | M-CLASS (W163) | ML 230 (163.136) | 1998 – 2005 | 2295 | 110 | 150 |
| MERCEDES-BENZ | M-CLASS (W163) | ML 430 (163.172) | 1998 – 2005 | 4266 | 200 | 272 |
| MERCEDES-BENZ | M-CLASS (W163) | ML 270 CDI (163.113) | 1998 – 2005 | 2685 | 120 | 163 |
| MERCEDES-BENZ | M-CLASS (W163) | ML 55 AMG (163.174) | 1998 – 2005 | 5439 | 255 | 347 |
| MERCEDES-BENZ | M-CLASS (W163) | ML 400 CDI (163.128) | 1998 – 2005 | 3996 | 184 | 250 |
| MERCEDES-BENZ | M-CLASS (W163) | ML 500 (163.175) | 1998 – 2005 | 4966 | 215 | 292 |
| MERCEDES-BENZ | M-CLASS (W163) | ML 350 (163.157) | 1998 – 2005 | 3724 | 180 | 245 |
| MERCEDES-BENZ | M-CLASS (W163) | ML 350 | 1998 – 2005 | 3724 | 173 | 235 |
