Specifications
| Axle Joint Length (mm) | 122 |
| Axle Joint Thread Size M14x1,5 | |
| Axle Joint Thread Type External Thread | |
| Connector Length (mm) | 27 |
| Distance of mounting bores (mm) | 263 |
| Input shaft connector type toothed | |
| Input Shaft Diameter (mm) | 17.6 |
| Left-/right-hand drive vehicles for left-hand drive vehicles | |
| Manufacturer Restriction THYSSEN KRUPP | |
| Number of Teeth on input shaft 54 | |
| Observe technical data | |
| Operating Mode Hydraulic | |
| Overall Length (mm) | 1126 |
| Vehicle Equipment for vehicles without servotronic steering | |
Axle Joint Length [mm] 122, Axle Joint Thread Size M14x1,5, Axle Joint Thread Type External Thread, Connector Length [mm] 27, Distance of mounting bores [mm] 263, Input shaft connector type toothed, Input Shaft Diameter [mm] 17,6, Left-/right-hand drive vehicles for left-hand drive vehicles, Manufacturer Restriction THYSSEN KRUPP, Number of Teeth on input shaft 54, Observe technical data , Operating Mode Hydraulic, Overall Length [mm] 1126, Vehicle Equipment for vehicles without servotronic steering
