Specifications
| Component Number 5BC-2011-I1.00 | |
| Component Number 5BC-2011-S1.00, for bearing clearance from (mm) | 0.018. for housing diameter from [mm] 63.708. for shaft diameter from [mm] 59.981. for wall thickness from [mm] 2.3370. to bearing clearance [mm] 0.072. to housing diameter [mm] 63.727. to shaft diameter [mm] 60.0. to wall thickness [mm] 2.3450 |
| Width from (mm) | 20.75 |
| Width to (mm) | 21.0 |
Component Number 5BC-2011-I1.00, Component Number 5BC-2011-S1.00, for bearing clearance from [mm] 0,018, for housing diameter from [mm] 63,708, for shaft diameter from [mm] 59,981, for wall thickness from [mm] 2,3370, to bearing clearance [mm] 0,072, to housing diameter [mm] 63,727, to shaft diameter [mm] 60,0, to wall thickness [mm] 2,3450, Width from [mm] 20,75, Width to [mm] 21,0
