Specifications
| for bearing clearance from (mm) | 0.036. for housing diameter from [mm] 92.0. for shaft diameter from [mm] 86.978. for wall thickness from [mm] 2.595 |
| Quantity Unit Pair, to bearing clearance (mm) | 0.104. to housing diameter [mm] 92.022. to shaft diameter [mm] 87.0. to wall thickness [mm] 2.607 |
| Width from (mm) | 25.7 |
| Width to (mm) | 26.0 |
for bearing clearance from [mm] 0,036, for housing diameter from [mm] 92,0, for shaft diameter from [mm] 86,978, for wall thickness from [mm] 2,595, Quantity Unit Pair, to bearing clearance [mm] 0,104, to housing diameter [mm] 92,022, to shaft diameter [mm] 87,0, to wall thickness [mm] 2,607, Width from [mm] 25,7, Width to [mm] 26,0
