Specifications
| Component Number 5BC-1126-I0.25 | |
| Component Number 5BC-1126-S0.25, for bearing clearance from (mm) | 0.02. for housing diameter from [mm] 59.0. for shaft diameter from [mm] 53.958. for wall thickness from [mm] 2.62. to bearing clearance [mm] 0.064. to housing diameter [mm] 59.012. to shaft diameter [mm] 53.978. to wall thickness [mm] 2.626 |
| Width from (mm) | 18.2 |
| Width to (mm) | 18.5 |
Component Number 5BC-1126-I0.25, Component Number 5BC-1126-S0.25, for bearing clearance from [mm] 0,02, for housing diameter from [mm] 59,0, for shaft diameter from [mm] 53,958, for wall thickness from [mm] 2,62, to bearing clearance [mm] 0,064, to housing diameter [mm] 59,012, to shaft diameter [mm] 53,978, to wall thickness [mm] 2,626, Width from [mm] 18,2, Width to [mm] 18,5
