Specifications
| for bearing clearance from (mm) | 0.017. for housing diameter from [mm] 47.007. for shaft diameter from [mm] 41.963. for wall thickness from [mm] 2.75. to bearing clearance [mm] 0.056. to housing diameter [mm] 47.019. to shaft diameter [mm] 41.978. to wall thickness [mm] 2.756 |
| Width from (mm) | 16.95 |
| Width to (mm) | 17.15 |
for bearing clearance from [mm] 0,017, for housing diameter from [mm] 47,007, for shaft diameter from [mm] 41,963, for wall thickness from [mm] 2,75, to bearing clearance [mm] 0,056, to housing diameter [mm] 47,019, to shaft diameter [mm] 41,978, to wall thickness [mm] 2,756, Width from [mm] 16,95, Width to [mm] 17,15
