Specifications
| Component Number 5BC-2008-I1.00 | |
| Component Number 5BC-2008-S1.00, for bearing clearance from (mm) | 0.014. for housing diameter from [mm] 52.0. for shaft diameter from [mm] 47.94. for wall thickness from [mm] 2.505. to bearing clearance [mm] 0.07. to housing diameter [mm] 52.02. to shaft diameter [mm] 47.96. to wall thickness [mm] 2.513 |
| Width from (mm) | 15.85 |
| Width to (mm) | 16.1 |
Component Number 5BC-2008-I1.00, Component Number 5BC-2008-S1.00, for bearing clearance from [mm] 0,014, for housing diameter from [mm] 52,0, for shaft diameter from [mm] 47,94, for wall thickness from [mm] 2,505, to bearing clearance [mm] 0,07, to housing diameter [mm] 52,02, to shaft diameter [mm] 47,96, to wall thickness [mm] 2,513, Width from [mm] 15,85, Width to [mm] 16,1
