Specifications
| Centering Diameter (mm) | 22.0 |
| Distance of mounting bores (mm) | 66.0. for shaft diameter [mm] 12.0 |
| Length (mm) | 147.0 |
| Net Weight (g) | 3500 |
| Packaging height (cm) | 13.60 |
| Packaging length (cm) | 25.0 |
| Packaging width (cm) | 16.60 |
| Power (kW) | 0.4 |
| Protection Type (IP Code) IP54 | |
| Rotation Direction Anticlockwise rotation | |
| Service Speed (1/min) | 4000 |
| Voltage (V) | 12 |
| Weight (kg) | 3.5 |
Centering Diameter [mm] 22,0, Distance of mounting bores [mm] 66,0, for shaft diameter [mm] 12,0, Length [mm] 147,0, Net Weight [g] 3500, Packaging height [cm] 13,60, Packaging length [cm] 25,0, Packaging width [cm] 16,60, Power [kW] 0,4, Protection Type (IP Code) IP54, Rotation Direction Anticlockwise rotation, Service Speed [1/min] 4000, Voltage [V] 12, Weight [kg] 3,5
