Specifications
| Centering Diameter (mm) | 56.0. for shaft diameter [mm] 18.0 |
| Length (mm) | 192.0 |
| Net Weight (g) | 7668 |
| Operating time to (min) | 3.0 |
| Packaging height (cm) | 17.50 |
| Packaging length (cm) | 24.8 |
| Packaging width (cm) | 18.60 |
| Power (kW) | 1.6 |
| Protection Type (IP Code) IP54 | |
| Rotation Direction Clockwise rotation | |
| Service Speed (1/min) | 2750 |
| Voltage (V) | 12 |
| Weight (kg) | 8.6 |
Centering Diameter [mm] 56,0, for shaft diameter [mm] 18,0, Length [mm] 192,0, Net Weight [g] 7668, Operating time to [min] 3,0, Packaging height [cm] 17,50, Packaging length [cm] 24,8, Packaging width [cm] 18,60, Power [kW] 1,6, Protection Type (IP Code) IP54, Rotation Direction Clockwise rotation, Service Speed [1/min] 2750, Voltage [V] 12, Weight [kg] 8,6
