Specifications
| Centering Diameter (mm) | 148.3 |
| Distance of mounting bores (mm) | 156. for shaft diameter [mm] 35 |
| Length (mm) | 294 |
| Power (kW) | 8 |
| Protection Type (IP Code) IP54 | |
| Rotation Direction Can be used in clockwise and anticlockwise direction | |
| Service Speed (1/min) | 7000 |
| Voltage (V) | 30 |
| Weight (kg) | 42 |
Centering Diameter [mm] 148,3, Distance of mounting bores [mm] 156, for shaft diameter [mm] 35, Length [mm] 294, Power [kW] 8, Protection Type (IP Code) IP54, Rotation Direction Can be used in clockwise and anticlockwise direction, Service Speed [1/min] 7000, Voltage [V] 30, Weight [kg] 42
