Specifications
| Bore Diameter 1 (mm) | 11.0 |
| Clamp 31 | |
| Flange Diameter (mm) | 89.0. for flywheel depth [mm] 32.5 |
| Mounting points diameter (mm) | 127.0 |
| Net Weight (g) | 13000 |
| Number of mounting bores 3 | |
| Number of Teeth 10 | |
| Packaging height (cm) | 14.40 |
| Packaging length (cm) | 36.5 |
| Packaging width (cm) | 21.60 |
| Rated Power (kW) | 3.0 |
| Rotation Direction Clockwise rotation | |
| Tooth Pitch (mm) | 15.42 |
| Voltage (V) | 12 |
Bore Diameter 1 [mm] 11,0, Clamp 31, Flange Diameter [mm] 89,0, for flywheel depth [mm] 32,5, Mounting points diameter [mm] 127,0, Net Weight [g] 13000, Number of mounting bores 3, Number of Teeth 10, Packaging height [cm] 14,40, Packaging length [cm] 36,5, Packaging width [cm] 21,60, Rated Power [kW] 3,0, Rotation Direction Clockwise rotation, Tooth Pitch [mm] 15,42, Voltage [V] 12
